3-34 EXCEN-Series EXCEN 带式喂料带式器的操作手册

3-33

维修与维护

No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

PART NO.

FC38-000044B

FC28-000218D

MC19-000193B

J70661291A

J70652830A

J70661292A

FC18-000303B

J71651465A

AM03-003749A

FC29-000716A

J70661293A

J70661257A

FC09-000865A

J70661295A

J70661254A

J70661259A

EP10-901401

FC07-000309A

FC07-000312B

MC19-000192B

Q'TY

2

2

2

1

3

1

1

1

1

1

1

1

1

1

2

1

1

1

1

1

PART NAME

V LOCKER FRONT SPRING-L

V LOCKER FRONT-L

V LOCKER FRONT SHAFT-L

D-TENSIONER L SPRING

FLANGED SHAFT

D-FOLLOWER L SPRING

V DRAIN LEVER PIN-L

MAIN LED LIGHT

UI ASSY VL

V HANDLE RIGHT-L

CLAMP SPRING

SPRING HOLDER

CLAMP HOOK

CLAMP HOOK SPRING

CLAMP ROLLER SHAFT

CLAMP LEVER

MAGNET

V SUPPORT BLOCK DRAIN-L

V SPLICING LEFT BLOCK-L

V D-STAGE GEAR1 SHAFT-L

No.

31

32

33

34

35

36

37

38

39

40

59

PART NO.

MC19-000184B

MC11-000235D

FC09-000951A

MC19-000197A

AM03-003844A

FC07-000307A

FC28-000214A

FC28-000217A

FC07-000309A

FC07-000310A

FC29-002015A

Q'TY

1

1

1

1

1

2

1

1

3

2

1

PART NAME

V D-GEAR SHAFT 32

V DRAIN GEAR 32

V D-GEAR BKT 32

V DRAIN HANDLE SHAFT 32

V D-FOLLOWER ASSY 32

V DRAIN BOX BLOCK-L

V D-BOX LINK1 32

V D-BOX DOOR 32

V SUPPORT BLOCK DRAIN-L

V SUPPORT BLOCK BOTTOM-L

V HOLE STOPPER 32

FC15-000576A

FC07-000304B

FC29-000699C

MC19-000171B

FC07-000308A

MC19-000181A

FC35-000036A

AM03-003843A

FC07-000306A

FC09-000954A

1

1

1

2

2

1

1

1

1

1

V DRAIN COVER-L

V TAPE RIGHT GUIDE 32

V TAPE GUIDE 32

V LOCKER LEVER SHAFT-L

V SUPPORT BLOCK INDEX-L

V D-TENSIONER HINGE 32

V D-TENSIONER ROLLER 32

V D-TENSIONER ASSY 32

V D-TENSIONER BLOCK 32

V D-GEAR BKT2 32

3-34

EXCEN-Series EXCEN

带式喂料带式器的操作手册

3-35

维修与维护
