5OM-1434-003_w.pdf - 第65页

2-8 0805-002 传感器 / 负载配置图 送料器安装台 Symbol Name Symbol Name -B6950 Feeder Clamp Lower Limit -B6951 Feeder Clamp Upper Limit -Y6930 Feeder Clamp 传感器 / 负载配置图 送料器安装台 -B6950,6951 -Y6930

100%1 / 151
2-70805-002
传感器 / 负载配置图 传送带 (NL、NA、NR)
传感器 / 负载配置图 传送带 (NL、NA、NR)
-B5301
-B420
1
-B053
1
-B410
2
-B520
1
-B4101
-M5
6
-M5
2
-M5
1
-M5
2
-B510
1
-B053
2
-B420
1
-Y083
6
-B420
2
-B053
2
-B4201,420
2
Amp
-M4
1
-B4102
-M41
-M51
-M55
-M53
-Y0842
-B5301
-B4202
-B4101
-B0812
-B0813
-Y0834
-Y0835
-B5501
-B5601
-B0817
-B0817
Symbol Name Symbol Name
-B0531 Support Pin Check -M41 Transfer Servomotor (NL)
-B0532 Support Pin Check -M51
NL-W1 Chute Width Changeable Servomotor
-B4101
NL Transferred PCB Detection Sensor (Deceleration)
-M52
NL-W2 Chute Width Changeable Servomotor
-B4102
NL Transferred PCB Detection Sensor (Stop)
-M53 NA Backup Servomotor
-B4201
NA Transferred PCB Detection Sensor (Deceleration)
-M55
NA-W1 Chute Width Changeable Servomotor
-B4202
NA Transferred PCB Detection Sensor (Stop)
-M56
NA-W2 Chute Width Changeable Servomotor
-B5101 NL Chute Width Changeable 1 Limit (+) -Y0834 Z Clamp Cylinder Valve 1 DN [NA]
-B5201 NL Chute Width Changeable 2 Limit (-) -Y0835 Z Clamp Cylinder Valve 1 UP [NA]
-B5301 NA Backup 1 Limit (+) -Y0836 Z Clamp Pressure Change 1 (NA)
-B5501 NA Chute Width Changeable 2 Limit (+) -Y0842 NA PCB Positioning Stopper 1 U/D Valve
-B5601 NA Chute Width Changeable 2 Limit (-)
-B0812 NA PCB Positioning Stopper 1 Upper Limit
Detection
-B0813 NA PCB Positioning Stopper 1 Lower Limit
Detection
-B0817 NL Output Conveyor PCB Discharging End
PCB Detection
2-80805-002
传感器 / 负载配置图 送料器安装台
Symbol Name Symbol Name
-B6950 Feeder Clamp Lower Limit
-B6951 Feeder Clamp Upper Limit
-Y6930 Feeder Clamp
传感器 / 负载配置图 送料器安装台
-B6950,6951
-Y6930
2-90710-001
传感器 / 负载配置图 定位
传感器 / 负载配置图 定位
Symbol Name Symbol Name
-B0508 Feeder Disengaged Latch Detection -B0913 Lifting Section Feeder Base Detection 2
-B0510 Lifted Suppressor Detection -B0914 Cylinder Upper Limit Detection
-B0910
Feeder Base Y Direction Positioning Check 1
-B0915 Cylinder Lower Limit Detection
-B0911
Feeder Base Y Direction Positioning Check 2
-Y0932 Feeder Base Ascending
-B0912 Lifting Section Feeder Base Detection 1 -Y0933 Feeder Base Descending
-B0910,0911
-B0914,0915
-Y0932,0933
-B0510 Amp
-B0510
-B0510 Amp
-Y0932,0933
-B0914,0915
-B0910,0911
-B0510
