OIS 9.3 / Installation Manual Ausgabe 07/2011 Edition
If you don't yet have a database, you'll see the following dialog:
Figure 3-14: Entering size of database
► Click Browse... if you want to choose another installation directory for the database.
► Enter the starting file size for the database files.
The default values are generally acceptable, and the files are allowed to grow as your database
expands.
► Continue by clicking the Next> button.
Figure 3-15: Entering number of days for storing production data
The production data is only saved in the database for a certain period.
► Specify the time for which the production data is to be retained in the database.
Values between 40 and 400 days are permitted.
16
OIS 9.3 / Installation Manual Ausgabe 07/2011 Edition
Figure 3-16: Selecting dialog languages for OIS LineConfig
► Select the desired languages.
The languages are only relevant for the OIS LineConfig dialog. German and English are
always installed.
► Continue by clicking the Next> button.
Figure 3-17: Reviewing settings
This shows a summary of the settings and entries you have made so far.
► Check the settings.
► If you wish to change your entries, click <Back to return to the appropriate dialog.
► Click Next> to start the actual installation process.
The software is then installed.
► Continue with section 3.2.3 on page 18.
17
OIS 9.3 / Installation Manual Ausgabe 07/2011 Edition
3.2.3 Installing OIS Client
NOTICE
OIS Server must be installed and running before installing OIS Client!
Figure 3-18: Selecting machine type
► Select the machine type on which OIS Client is to be installed.
► Select the Personal Computer type for machines with station software version 70x.
► Continue by clicking the Next> button.
18
