Page 15
TECHNICAL PUBLICATIONS
DH Positioning System Assembly, P/T T46230812 Rev. D
This Document Supports Assembly 46230812
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
31 20267000 SUPPORT,BRG 1 EA
32 80000604 SHCS 1/4-20 X 5/8 12 EA
33 15102001 PULLEY,GEARBELT 3 EA
34 80005803 SSSCNP 10-24 X 1/2 3 EA
35 46684301 BEARING,BALL 2 EA
36 80001302 SBHS 4-40 X 3/8 6 EA
37 46311302 ACTUATOR ASSEMBLY 1 EA
38 20266000 SHAFT 1 EA
39 15092000 GEARBELT 1 EA
40 46987301 BLOCK, X STOP 1 EA
41 46910201 ROTARY ENCODER ASSY 2 EA
42 17691000 SUPPORT, BRG 1 EA
43 10593001 BEARING,BALL 2 EA
44 17689000 BLOCK,BRG 1 EA
45 80009904 DOWEL 1/8 DIA X 3/4 2 EA
46 BLKM06320 RETAINING RING 2 EA
47 22260003 VINYL/.25 FOAM 1 EA
48 46278403 ARM, ACTUATOR 2 EA
49 80001602 SBHS 10-24 X 3/8 4 EA
50 80018704 SLW #8 11 EA
51 22260002 VINYL/.25 FOAM 1 EA
52 30587603 BRACKET,LOCKING 4 EA
53 80001501 SBHC 8-32 X 1/4 4 EA
54 46312601 GUIDEWHEEL BEARING ASSY 4 EA
55 46277702 STUD,GUIDE WHEEL 4 EA
56 80018804 FW #8 7 EA
57 17656001 PLATE,MTG. 1 EA
58 80001602 SBHS 10-24 X 3/8 4 EA
59 17700001 COVER,Y FRAME 1 EA
60 80001402 SBHS 6-32 X 3/8 1 EA
Page 16
TECHNICAL PUBLICATIONS
T46230812 Rev. D DH Positioning System Assembly, P/T
This Document Supports Assembly 46230812
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
61 46247901 GUIDE,PLATE 1 EA
62 46247803 GUIDE,REAR BOARD 1 EA
63 46247406 GUIDE,BOARD 1 EA
64 22243011 VINYL,DAMPING 2 EA
65 22243016 VINYL,DAMPING 1 EA
66 46987201 STOP,X 1 EA
67 46247405 GUIDE,BOARD 1 EA
68 80014904 SPRING,PIN 1 EA
69 18333000 COLLAR 4 EA
70 80010102 DOWEL 1/4 DIA X 5/8 11 EA
71 80000710 SHCS 5/16-18 X 2 1 EA
72 80000707 SHCS 5/16-18 X 1 1/4 1 EA
73 80018806 FW #10 32 EA
74 80018705 SLW #10 49 EA
75 80015103 HEX JAM NUT 5/16-18 2 EA
76 80018706 SLW 1/4 5 EA
77 80001704 SBHS 1/4-20 X 3/4 12 EA
78 80000110 SHCS 4-40 X 5/16 8 EA
79 30395801 STOP, Y 1 EA
80 80015101 HEX JAM NUT 1/4-20 1 EA
81 46194901 STOP, X 1 EA
82 80010506 DOWEL 1/2 DIA X 2 1 EA
83 14330003 RETAINER,BELLOW 2 EA
84 46217002 ROTARY TABLE ASSY 2 EA
85 80000405 SHCS 8-32 X 3/4 2 EA
86 80001011 SHCS 1/2-13 X 2 1/2 6 EA
87 48226601 PLATE,MOTOR 1 EA
88 80001802 SBHS 5/16 -18 X 1/2 2 EA
89 47527101 LOCKING ELEMENT 4 EA
90 T46230812 DOC,POSITIONING STSTEM ASSY P/T 1 EA
Page 17
TECHNICAL PUBLICATIONS
DH Positioning System Assembly, P/T T46230812 Rev. D
This Document Supports Assembly 46230812
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
91 40200106 C FRAME 1 EA
92 46564804 PULLEY,GEARBELT 2 EA
93 30587602 BRACKET, LOCKING 4 EA
94 30780801 SPACER 4 EA
95 80001606 SBHS 10-24 X 7/8 4 EA
96 80000515 SHCS 10-32 X 1/2 2 EA
97 30648002 DRIVE ASSY 2 EA
98 80002612 SFHS 10-32 X 1 4 EA
99 80023508 HEX NUT-MS 10-32 4 EA
100 BLKE01073 CABLE CLAMP,5/16,BLACK 2 EA
101 80008602 PHMS 8-32 X 1/4 2 EA
102 42372703 X FRAME 2 EA
103 15055000 BUSHING,BALL 8 EA
104 30013000 PLUNGER,SPRING 8 EA
105 18388000 RETAINER 8 EA
106 46194802 BLOCK,SUPPORT 1 EA
107 80000606 SHCS 1/4-20 X 7/8 4 EA
108 48253601 BELLOW,DUST 1 EA
109 80010003 DOWEL 3/16 DIA X 3/4 1 EA
110 80000603 SHCS 1/4-20 X 1/2 11 EA
111 80000407 SHCS 8-32 X 1 5 EA
112 48240101 PLATE,MOTOR 1 EA
113 80001610 SBHS 10-32 X 1/2 8 EA
114 42372601 TROLLEY,ROT 2 EA
115 46587901 GEAR BELT 2 EA
116 17615000 CAM 2 EA
117 18058000 LOCK ASSY 2 EA
118 40395901 MECH SLOWDOWN ASSY 1 EA
119 80007601 HHCS 1/4 X 1/2 3 EA
120 80015001 HEX NUT 1/4-20 1 EA
