Page 18
TECHNICAL PUBLICATIONS
T46230812 Rev. D DH Positioning System Assembly, P/T
This Document Supports Assembly 46230812
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
121 40395902 MECH SLOWDOWN ASSY 1 EA
122 40395803 PULSE VALVE ASSY 1 EA
123 BLKE01079 CLAMP,1 1 EA
124 80019006 ITLW 1/4 4 EA
125 40395802 PULSE VALVE ASSY 1 EA
126 80000409 SHCS 8-32 X 1 1/2 1 EA
127 30902801 BUSHING 4 EA
128 80032701 EXT, TOOTH L/W CSK 4 EA
129 80001502 SBHS 8-32 X 1/2 8 EA
130 20981000 BUSHING, ADAPTOR 4 EA
131 18164000 WHEEL,GUIDE 4 EA
132 47540603 STUD,GUIDE WHEEL 4 EA
133 17597001 Y FRAME 1 EA
134 14339000 SHAFT,X AXIS 2 EA
135 80000519 SHCS 10-32 X 1 19 EA
136 80004704 SOC SET SCR,FL.PT 6-32 X 3/8 4 EA
137 20189000 ACTUATOR 2 EA
138 48240001 SPACER 2 EA
139 15118000 BUSHING 3 EA
140 80000517 SHCS 10-32 X 3/4 3 EA
141 80000302 SHCS 6-32 X 3/8 18 EA
142 45292801 RAIL,ACTUATOR BRKT 1 EA
143 80002403 SFHS 6-32 X 1/2 3 EA
144 80000609 SHCS 1/4-20 X 1 1/2 1 EA
145 48226801 PLATE,ENCODER 1 EA
146 14330002 RETAINER, BEARING 1 EA
147 80001501 SBHS 8-32 X 1/4 4 EA
148 14340000 SUPPORT,BRG 1 EA
149 80000608 SHCS 1/4-20 X 1 1/4 5 EA
150 17802000 PLATE,MTG 1 EA
Page 19
TECHNICAL PUBLICATIONS
DH Positioning System Assembly, P/T T46230812 Rev. D
This Document Supports Assembly 46230812
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
151 17595002 COVER 1 EA
152 48216301 MOTOR,BRUSHLESS,DC,ENCODER 2 EA
153 48236102 RETAINER,BELLOW 2 EA
154 80015104 HEX JAM NUT 5/16-24 2 EA
155 44973301 BRACKET,SENSOR 2 EA
156 44460003 PROXIMITY SWITCH 2 EA
157 80002503 SFHS 8-32 X 5/8 6 EA
158 80010104 DOWEL, 1/4 X 7/8 4 EA
159 15179000 CLAMP,ENCODER 1 EA
160 48237501 BEARING,BALL,DOUBLE ROW 2 EA
161 10249101 SPRING 4 EA
162 80010407 SDP 7/16 X 1/2 4 EA
163 80010403 SDP 7/16 X 1 1/2 2 EA
164 80000607 SHCS 1/4-20 X 1 2 EA
165 80004909 SSSFP 10-32 X 1/2 1 EA
166 BLKE01071 CLAMP, 3/16 2 EA
167 80018807 FW 1/4 2 EA
168 48213801 PULLEY,MOTOR 2 EA
169 10457013 CLAMP,COLLAR 2 EA
170 48239901 SPACER 2 EA
171 18332000 SCREW, THUMB 2 EA
172 48236201 RETAINER,BEARING 2 EA
173 48395101 CABLE ASSY,LIMIT WIRE 1 EA
Page 20
TECHNICAL PUBLICATIONS
T46230812 Rev. D DH Positioning System Assembly, P/T
This Document Supports Assembly 46230812
Functional Description
The dual X-Y positioning system contains the X and Y positioning tables
which are actuated by the servo drive motors. When the motors receive a
signal they move the positioning system to predetermined coordinates
contained in the pattern program. Rotary encoders monitor the positioning
system location to ensure the positional accuracy. The X and Y tables mount
on the base and position the dual rotary tables.
Maintenance Concept
The following table defines the recommended Maintenance Concept for this
assembly. For a more detailed explanation of the Maintenance Concept and
its structure refer to the Prerequisite Information/Introduction module and the
periodic preventive maintenance as presented later in this document.
Maintenance Procedure
Recommended
Frequency
Minimum Skill
Requirement
Spares Kit
Required
Tool Kit
Required
Check rotary table squareness Weekly
Maintenance
Technician
No Yes
Check rotary table air motor drive
whee
l
Weekly
Maintenance
Technicia
n
No No
Lubricate the rotary table lock
assembl
y
Weekly
Maintenance
Technicia
n
No No
Flush and lubricate the X-Y ball
bushin
gs
Monthly
Maintenance
Technicia
n
No No
Clean and lubricate linear shafts Monthly
Maintenance
Technician
No No
Lubricate X-Y ball screws Monthly
Maintenance
Technician
No No
Disassemble, clean and lubricate
rotary table lock assy
Semiannually
Maintenance
Technician
No Yes
Prerequisite Information
• See the Prerequisite Information/Introduction document for Adhesive
and Lubricant icon information and definitions.
