Structural Requirements 3
Site Preparation 3-3
Moving Access Requirements
The system is shipped from the factory on one large crate (on a pallet) and several
smaller crates or boxes. If the large testhead crate is too large to move to your
system’s destination, you will need to unpack the testhead and roll it on its casters.
Other smaller boxes, containing the controller and test development hardware,
should not present access problems.
This section contains:
• Dimensions of the Crated System
• Dimensions of the Uncrated System
• Access Requirements
Dimensions of the Crated System
Table 3-2 Dimensions of the crated system
System Type Dimension Measurement
E9903G/E9902G Width 2153 mm
Depth 1220 mm
Height 1400 mm
E9905G Width 1617 mm
Depth 1220 mm
Height 1400 mm
3-4 Site Preparation
3 Structural Requirements
Dimensions of the Uncrated System
When removed from the crate, the testhead can be rolled on its casters.
Table 3-3 lists the dimensions of the uncrated testhead.
Equipment Rating
• Pollution degree 2
• Installation category II
• Altitude: Up to 2000 m
• Humidity: 5% to 80%
• Electrical supply: 208 Vac or 415 Vac, 50/60Hz, 30 A max, 3 phase
• Temperature: 0°C to 40°C
• Mains supply voltage fluctuations are not to exceed 10% of the nominal supply
voltage
This equipment is for indoor use only.
Table 3-3 Dimensions of the uncrated system
System Type Dimension Measurement
E9903G/E9902G Width 1490 mm
Depth 935 mm
Height 887 mm
E9903G/E9902G with side pod Width 1765 mm
Depth 935 mm
Height 887 mm
E9905G Width 954 mm
Depth 935 mm
Height 887 mm
E9905G with side pod Width 1229 mm
Depth 935 mm
Height 887 mm
Structural Requirements 3
Site Preparation 3-5
Access Requirements
• Ramps
When moved on its casters, the testhead will negotiate ramps with inclines up
to 12% before the leveling feet drag on the floor.
• Hallways and door
As a rough guide, if you have room to move a 1.25 m x 2.5 m (4 by 8-foot) sheet
of plywood, parallel to the floor, through hallways and doors, you will be able to
move the crated testhead. If you cannot move the testhead crate all the way,
remove it from its crate in a receiving area and push it on its casters to the
destination.
