5M-1751-004w_G5S.pdf - 第106页
3-5 Parts Location 5OM-1751 1305-002 Noise Filter Z1 Z2 Symbol Name Remarks Z1 FIL TER-NOISE 1 Z2 FIL TER-NOISE 2
3-4
Parts Location
5OM-1751
1305-002
Power Breaker
Q200
Symbol Name Remarks
Q200 Main Breake
3-5
Parts Location
5OM-1751
1305-002
Noise Filter
Z1
Z2
Symbol Name Remarks
Z1 FILTER-NOISE 1
Z2 FILTER-NOISE 2
3-6
Parts Location
5OM-1751
1305-002
LED Light Control PCB
CON1
CON2
CON3
CON4
CON5
CON6
CON7
CON8
CN5
CN1
CN8
CN7
CN3
CN2
CN6
CON10
A21F
X(B2)
ADD:3
A22F
Y1(B2)
ADD:4
A23F
Y2(B2)
ADD:5
U95
Lighting Ctrl
PCB
U95
Symbol Name Remarks
U95 LED Light Control PCB Model UC19
