1
1OM-1751
1303-001
Before Use
We are grateful to you for purchasing Yamaha modular mounter (chip mounter).
This machine can be used to place the chip-type electronic components on PCBs.
This instruction manual describes the functions, handling, and operations of the machine for
those who have nished the basic training of the chip mounter.
Before operating the machine, please read this instruction manual carefully to fully
understand the instructions and precautionary measures for safety purposes.
After reading through this manual, please use this manual as an occasional reference and
keep it within reach.
2
1OM-1751
1303-001
About the Instruction Manual
This instruction manual is divided into the following six volumes (booklets) on subjective
basis.
Volume 1 : Guide
This describes the basic usage of the machine and is prepared for those who will read
this manual for the rst time or have never used any modular mounter.
[Coverage]
"Checking Items", "Safety Precautions", "Guide Map for Machine and
Operations", "Functions", "Procedures from Preparation to Completion of
Automatic Operation", and "Specications"
Volume 2 : Product & Set-up Menu
This describes the product menu and setup menu for those who have read "Volume 1:
Guide".
[Coverage]
"Checking Items", "Safety Precautions", "Automatic Operation", "Program/
Product Change Operations", "Pattern Programs", "Manage Data", etc.
Volume 3 : Maintenance Menu
This describes the maintenance menu for those who have read "Volume 1: Guide".
[Coverage]
"Checking Items", "Safety Precautions", "Device Check", "Various Operations",
"Shipment Adjust", "System Setting", etc.
Volume 4 : Maintenance & Troubleshooting
This describes the periodic maintenance and troubleshooting for the machine operators.
[Coverage]
"Checking Items", "Safety Precautions", "Periodic Maintenance", "List of
Consumables and Servicing Parts", "Remedial Measures after "ERROR"
Window", etc.
Volume 5 : Pneumatic and Machine Diagrams
This provides various kinds of material such as pneumatic and electrical circuit
diagrams, etc.
[Coverage]
"Checking Items", "Safety Precautions", "Pneumatic Diagrams", "Parts
Location", "Electrical Circuit Diagrams", etc.
