Installation Manual SIPLACE EDM Edition 11/2006
3.2 Forced pull mode
In order to have some influence on this situation, SIPLACE Pro provides the “forced pull mode”. This
mode allows for the specification of a maximum time period between two downloads. This should
ensure that the data on the lines is never older than the prescribed time period. If no data is
downloaded from the master server during the time period defined, then the data preparation
engineer is informed of this via a SIPLACE EDM notification and can initiate organizational activities
to ensure the data is downloaded and up-to-date.
10 of 66
Installation Manual SIPLACE EDM Edition 11/2006
4 Installation
4.1 Requirements
4.1.1 EDM master server
Minimum Requirements
Hardware Intel Pentium 4.3 GHz
2 GB RAM
1 GB hard disk storage capacity
Network connection
Operating system Windows 2003 Server (with SP1)
Windows XP Professional SP2
MSMQ Runtime must be installed
SIPLACE Pro 4.1 or higher, server installation
Microsoft SQL Server V8.0 SP 4 or MSDE 2000 SP 4 (same as SIPLACE Pro)
.NET Framework V2.0
Table 1 EDM master server software requirements
4.1.2 EDM line server
Minimum Requirements
Hardware Intel Pentium 4
1 GB RAM
Network connection
Operating system Windows 2003 Server (with SP1)
Windows XP Professional SP2
MSMQ Runtime must be installed
SIPLACE Pro 4.1 or higher, complete installation
License for SPI system monitor interface
11 of 66
Installation Manual SIPLACE EDM Edition 11/2006
Microsoft SQL Server V8.0 SP 4 or MSDE 2000 SP 4 (same as SIPLACE Pro)
.NET Framework V2.0
Table 2 EDM line server software requirements
4.1.3 Clearing pool
Minimum Requirements
Hardware Intel Celeron 1.7 GHz
512 MB RAM
Network connection
Operating system Windows 2003 Server (with SP1)
Windows XP Professional SP2
MSMQ Runtime must be installed
SIPLACE Pro SIPLACE Pro Desk 4.1
Table 3 Clearing pool software requirements
Attention:
Before installing a ClearingPool on your local PC, that has access to a remote EDM master,
you must install SIPLACE Pro Desk on your local system. Thereby, SIPLACE Pro Desk must
also have access to the remote EDM Master.
12 of 66
