Installation Manual SIPLACE EDM Edition 11/2006
The following shows the basic structure of an EDM configuration file:
<configuration>
<!- - This is a comment - - >
<appSetting>
<add key=“masterServer” value=“localhost”/>
<add key=“notificationInterval” value=“P0Y0M0D0H15M0S”/>
Value
Time
</appSettings>
Key
<! - - This is a configuration parameter of the type “Section” - ->
<endpointConfig>
Endpoint
<add key=“spc10047c” value=“private$\EDM”/>
</endpointConfig>
Section
<! - - These are the services provided by the master server - - >
<requestCommandConfig>
<add key="objectData" value=
"Siemens.SiplacePro.EDM.DataExchange.Commands.RequestDataCommand,DataExchange"
/>
Class
</requestCommandConfig>
</configuration>
The keys and sections permitted are shown in the following table:
Key Format Type Contents
clientWorkflowConfig File L;D File with EDM client process
definition (5.2.3.21)
commentCategories Section M;T Comment categories for change
notifications (5.2.3.29)
communicationTimeout Time L;M;C;D Timeout für Kommunikation zw.
Line und Master-Server (5.2.3.16)
compressionType Enum L;M;C;D Compression for data transfer
(5.2.3.20)
customConfig Section L;M ;C ;T Space for additional attributes
(5.2.3.32)
edmToolEndPoint Endpoint L;M;T;R End point for messages to the EDM
27 of 66
Installation Manual SIPLACE EDM Edition 11/2006
tool. (5.2.3.14)
endpointConfig Section M;R Endpoint configuration for the
exchange of data (5.2.3.15)
helpDirectory Path L;M;C;T;
D
Path for help files (5.2.3.2)
incomingClearingPoolRequests Endpoint M;C;R Endpoint for incoming queries to
the clearing pool (5.2.3.13)
incomingNotifications Endpoint M;R Endpoint for incoming change
notifications to the master
(5.2.3.12)
incomingRequests Endpoint M;R Endpoint for incoming change
queries to the master (5.2.3.11)
machineAliasNames Section L;M;C;R Assignment of readable names to
the network IDs of the individual
EDM computers (line servers,
clearing pool, etc.) (5.2.3.31)
masterNotifications Endpoint L;R Destination for change notifications
(5.2.3.10)
masterRequests Endpoint L;C;R Requests to the master server
(5.2.3.9)
masterServer String L;M;C;R Network identification of the master
server (5.2.3.7)
notificationDistributorClass Class M;D Class for external notifications (e.g.
email) (5.2.3.3)
notificationDistributorConfiguratorClass Class M;D Configuration for external
notification system (e.g. email)
(5.2.3.4)
notificationInterval Time L;D Time to transfer the change
notification to the master (5.2.3.5)
notificationStorage Endpoint L;D Buffer for change notifications
(5.2.3.6)
responseTimeout Time L;D Timeout for replies from the master
(5.2.3.19)
requestCommandConfig Section M;R Scope of functionality of master
server (5.2.3.30)
serverType Enum L;M;C;R Operating mode of the installation
(5.2.3.1)
28 of 66
Installation Manual SIPLACE EDM Edition 11/2006
serviceRemotingEndpoint String L;R .NET remoting configuration for
communication with the line service
(5.2.3.22)
spiLines Section L SPI lines associated with this line
server. (5.2.3.24)
startingPoints Section M List of permissible object types for
starting points (5.2.3.28)
sqlDataSource String C;M;R SQL Server access for the clearing
pool (5.2.3.24)
sqlUserName String C;M;R User name for SQL Server access
(5.2.3.26)
sqlUserPassword String C;M;R Password for SQL Server access
(5.2.3.27)
templateStorage Path L;M;D Storage location for application
templates (5.2.3.23)
transceiverClass Class L;M;C;T;
D
Class of data transfer (5.2.3.8)
useAdvancedNotificationFiltering String
(“true”/”false”)
M;D Activate/deactivate direct
import/rejection of notifications in
the master server (5.2.3.17)
useModifiedObjectProtection String
(“true”/”false”)
L;D Forced overwriting of changed
objects with older master data
(5.2.3.18)
useBlobExtension String
(“true”/”false”)
L;M;D Activates/deactivates EDM VDM
blob extensions (5.2.3.32)
xmlImportVisionDataAdvancedAction Integer L;M;C;D Sets the
VisionDataAdvancedAction
property of XmlImport.
Table 7 Contents of the configuration file
