4 Electrical Section
4-12
■ Device 3
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Head B1 Vacuum 0004h 0
Inside Infrared Light for Main Teach Camera
B: Calibration Bit0
1 Head B2 Vacuum 1
Inside Infrared Light for Main Teach Camera
B: Calibration Bit1
2 Head B3 Vacuum 2
Inside Infrared Light for Main Teach Camera
B: Calibration Bit2
3 Head B4 Vacuum 3
Inside Infrared Light for Main Teach Camera
B: Calibration Bit3
4 Head B5 Vacuum 4
Inside Infrared Light for Main Teach Camera
B: Calibration Bit4
5 Head B6 Vacuum 5
Inside Infrared Light for Main Teach Camera
B: Calibration Bit5
6 Head B7 Vacuum 6
Inside Infrared Light for Main Teach Camera
B: Calibration Bit6
7 Head B8 Vacuum 7
Inside Infrared Light for Main Teach Camera
B: Calibration Bit7
0001h 0 Head B1 Vacuum Break 0005h 0
Inside Infrared Light for Main Teach Camera
B: Adjustment Bit0
1 Head B2 Vacuum Break 1
Inside Infrared Light for Main Teach Camera
B: Adjustment Bit1
2 Head B3 Vacuum Break 2
Inside Infrared Light for Main Teach Camera
B: Adjustment Bit2
3 Head B4 Vacuum Break 3
Inside Infrared Light for Main Teach Camera
B: Adjustment Bit3
4 Head B5 Vacuum Break 4
5 Head B6 Vacuum Break 5
6 Head B7 Vacuum Break 6
7 Head B8 Vacuum Break 7
0002h 0
Outside Infrared Light for Main Teach Camera
B: Calibration Bit0
0006h 0
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit0
1
Outside Infrared Light for Main Teach Camera
B: Calibration Bit1
1
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit1
2
Outside Infrared Light for Main Teach Camera
B: Calibration Bit2
2
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit2
3
Outside Infrared Light for Main Teach Camera
B: Calibration Bit3
3
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit3
4
Outside Infrared Light for Main Teach Camera
B: Calibration Bit4
4
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit4
5
Outside Infrared Light for Main Teach Camera
B: Calibration Bit5
5
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit5
6
Outside Infrared Light for Main Teach Camera
B: Calibration Bit6
6
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit6
7
Outside Infrared Light for Main Teach Camera
B: Calibration Bit7
7
Coaxial Visible Light for Main Teach Camera
B: Calibration Bit7
0003h 0
Outside Infrared Light for Main Teach Camera
B: Adjustment Bit0
0007h 0
Coaxial Visible Light for Main Teach Camera
B: Adjustment Bit0
1
Outside Infrared Light for Main Teach Camera
B: Adjustment Bit1
1
Coaxial Visible Light for Main Teach Camera
B: Adjustment Bit1
2
Outside Infrared Light for Main Teach Camera
B: Adjustment Bit2
2
Coaxial Visible Light for Main Teach Camera
B: Adjustment Bit2
3
Outside Infrared Light for Main Teach Camera
B: Adjustment Bit3
3
Coaxial Visible Light for Main Teach Camera
B: Adjustment Bit3
4 4
5 5
6 6
7 7
4 Electrical Section
4-13
Address Bit No. Signal Name Address Bit No. Signal Name
000Ah 0
Outside Visible Light for Main Teach Camera
B: Calibration Bit0
000Dh 0
Inside Visible Light for Main Teach Camera B:
Adjustment Bit0
1
Outside Visible Light for Main Teach Camera
B: Calibration Bit1
1
Inside Visible Light for Main Teach Camera B:
Adjustment Bit1
2
Outside Visible Light for Main Teach Camera
B: Calibration Bit2
2
Inside Visible Light for Main Teach Camera B:
Adjustment Bit2
3
Outside Visible Light for Main Teach Camera
B: Calibration Bit3
3
Inside Visible Light for Main Teach Camera B:
Adjustment Bit3
4
Outside Visible Light for Main Teach Camera
B: Calibration Bit4
4
5
Outside Visible Light for Main Teach Camera
B: Calibration Bit5
5
6
Outside Visible Light for Main Teach Camera
B: Calibration Bit6
6
7
Outside Visible Light for Main Teach Camera
B: Calibration Bit7
7
000Bh 0
Outside Visible Light for Main Teach Camera
B: Adjustment Bit0
000Eh 0 DLC LIGHT-ON B
1
Outside Visible Light for Main Teach Camera
B: Adjustment Bit1
1 Beam Sensor Power On
2
Outside Visible Light for Main Teach Camera
B: Adjustment Bit2
2 Light Select
3
Outside Visible Light for Main Teach Camera
B: Adjustment Bit3
3
4 4
5 5
6 6
7 7
000Ch 0
Inside Visible Light for Main Teach Camera B:
Calibration Bit0
000Fh 0 Light Adjustment Frequency B Bit0
1
Inside Visible Light for Main Teach Camera B:
Calibration Bit1
1 Light Adjustment Frequency B Bit1
2
Inside Visible Light for Main Teach Camera B:
Calibration Bit2
2 Light Adjustment Frequency B Bit2
3
Inside Visible Light for Main Teach Camera B:
Calibration Bit3
3
4
Inside Visible Light for Main Teach Camera B:
Calibration Bit4
4
5
Inside Visible Light for Main Teach Camera B:
Calibration Bit5
5
6
Inside Visible Light for Main Teach Camera B:
Calibration Bit6
6
7
Inside Visible Light for Main Teach Camera B:
Calibration Bit7
7
4 Electrical Section
4-14
■ Device 5
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Switch Lamp State Bit0 0002h 0 Front Cover Lock
1 Switch Lamp State Bit1 1 Enable Front-side Operation
2 Switch Lamp Address Bit0 2
3 Switch Lamp Address Bit1 3
4 Switch Lamp Address Bit2 4
5 Switch Lamp Address Bit3 5
6 6
7 7
■ Device 7
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Switch Lamp State Bit0 0002h 0 Rear Cover Lock
1 Switch Lamp State Bit1 1 Enable Rear-side Operation
2 Switch Lamp Address Bit0 2
3 Switch Lamp Address Bit1 3
4 Switch Lamp Address Bit2 4
5 Switch Lamp Address Bit3 5
6 6
7 7
■ Device 9
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Board Stopper Up A 0002h 0 Main Clamp Up C
1 Main Clamp Up A 1 Entrance Shutter Close
2 Buffer Stopper Up / Board Stopper Up B 2 Exit Shutter Close
3
Conveyor1 Sensor POWER / Conveyor1
Sensor POWER
3 Conveyor2 Sensor POWER
4 ANC A Open 4 MX-ST2 R Clamp ON
5 ANC B Open 5
MX-ST2 Clamp ON / MX-ST2 L Clamp ON /
Swap-tray C No Component Alarm
6
CFB(F) Lock / Swap-tray A No Component
Alarm
6
7 CFB(F) Unlock 7
0001h 0
CFB(R) Lock / Swap-tray A No Component
Alarm
0003h 0
1 CFB(R) Unlock 1
2 Feeder Bank Power Supply(F60) ON 2
3 Feeder Bank Power Supply(F22) ON 3
4 BOARD AVAILABLE Output 4 ANC C Open
5 READY Output 5
Board Stopper Up Center (option) / AMF
Vacuum Stage
6 Side Clamp ON / Main Clamp Up B 6 Feeder Bank Power Supply(R60) ON
7 Rear Clam ON / Board Stopper Up C 7 Feeder Bank Power Supply(R22) ON
