4 Electrical Section 4-22 ■ Device 8 Address Bit No. Signal Name Address Bit No. Signal Name 0000h 0 Device No. Bit0 0002h 0 Start(R) 1 Device No. Bit1 1 Cy cle Stop(R) 2 Device No. Bit2 2 Cancel(R) 3 Device Added Inform…

4 Electrical Section

4-21

Address Bit No. Signal Name Address Bit No. Signal Name

0010h 0 Air Pressure: Head B7 Bit 0 0014h 0 INP BZ1

1 Air Pressure: Head B7 Bit 1 1 INP BZ2

2 Air Pressure: Head B7 Bit 2 2 INP BZ3

3 Air Pressure: Head B7 Bit 3 3 INP BZ4

4 Air Pressure: Head B7 Bit 4 4 INP BZ5

5 Air Pressure: Head B7 Bit 5 5 INP BZ6

6 Air Pressure: Head B7 Bit 6 6 INP BZ7

7 Air Pressure: Head B7 Bit 7 7 INP BZ8

0012h 0 Air Pressure: Head B8 Bit 0 0015h 0 INP BR1

1 Air Pressure: Head B8 Bit 1 1 INP BR2

2 Air Pressure: Head B8 Bit 2 2 INP BR3

3 Air Pressure: Head B8 Bit 3 3 INP BR4

4 Air Pressure: Head B8 Bit 4 4 INP BR5

5 Air Pressure: Head B8 Bit 5 5 INP BR6

6 Air Pressure: Head B8 Bit 6 6 INP BR7

7 Air Pressure: Head B8 Bit 7 7 INP BR8

■ Device 6

Address Bit No. Signal Name Address Bit No. Signal Name

0000h 0 Device No. Bit0 0002h 0 Start(F)

1 Device No. Bit1 1 Cycle Stop(F)

2 Device No. Bit2 2 Cancel(F)

3 Device Added Information Bit0 3 Alarm Off(F)

4 Device Added Information Bit1 4 Recovery(F)

5 Device Added Information Bit2 5 Servo(F)

6 Device Added Information Bit3 6 Enable(F)

7 Output Register Value Bit0 7 Setup(MXR)

0001h 0 Output Register Value Bit1 0003h 0 Setup(CFB-F)

1 Output Register Value Bit2 1 Go Rear(F)

2 Output Register Value Bit3 2 Auto/Manual Select Switch (F) (1:Auto)

3 Output Register Value Bit4 3 EMG(F)

4 Input Register Value Bit0 4 Front Cover OPEN Detection

5 Input Register Value Bit1 5 EMG Stop External Input

6 Input Register Value Bit2 6 Slowdown External Input

7 Input Register Value Bit3 7

4 Electrical Section

4-22

■ Device 8

Address Bit No. Signal Name Address Bit No. Signal Name

0000h 0 Device No. Bit0 0002h 0 Start(R)

1 Device No. Bit1 1 Cycle Stop(R)

2 Device No. Bit2 2 Cancel(R)

3 Device Added Information Bit0 3 Alarm Off(R)

4 Device Added Information Bit1 4 Recovery(R)

5 Device Added Information Bit2 5 Servo(R)

6 Device Added Information Bit3 6 Enable(R)

7 Output Register Value Bit0 7 Setup(MXR)

0001h 0 Output Register Value Bit1 0003h 0 Setup(CFB-R)

1 Output Register Value Bit2 1 Go Front(R)

2 Output Register Value Bit3 2 Auto/Manual Select Switch (R) (1:Auto)

3 Output Register Value Bit4 3 EMG(R)

4 Input Register Value Bit0 4 Rear Cover OPEN Detection

5 Input Register Value Bit1 5 EMG Stop External Input

6 Input Register Value Bit2 6 Slowdown External Input

7 Input Register Value Bit3 7

■ Device 10

Address Bit No. Signal Name Address Bit No. Signal Name

0000h 0 Device No. Bit0 0002h 0 Board Stopper Up A

1 Device No. Bit1 1 Main Clamp Up A

2 Device No. Bit2 2 Board Arrival B

3 Device Added Information Bit0 3

4 Device Added Information Bit1 4

5 Device Added Information Bit2 5 Board Stopper Up B

6 Device Added Information Bit3 6

7 Output Register Value Bit0 7 Entrance Sensor

0001h 0 Output Register Value Bit1 0003h 0 Entrance Shutter Close

1 Output Register Value Bit2 1

2 Output Register Value Bit3 2

3 Output Register Value Bit4 3 Main Conveyor Arrival A

4 Input Register Value Bit0 4 Exit Sensor

5 Input Register Value Bit1 5 Exit Shutter Close

6 Input Register Value Bit2 6

7 Input Register Value Bit3 7

4 Electrical Section

4-23

Address Bit No. Signal Name Address Bit No. Signal Name

0004h 0 X AB Deceleration 0008h 0 Board Stopper Up C

1 X BC Deceleration 1 Main Clamp Up C

2 2 Board Arrival Center (option)

3 3

4 AX-axis ORG 4

5 AX-axis OR+ 5

6 CX-axis ORG 6 Board Arrival C

7 7 Board Stopper Up Center (option)

0005h 0 0009h 0

1 1

2 CX-axis OR- 2

3 BX-axis ORG 3 Main Clamp Up B

4 Air Pressure Down (failure) 4

5 Ready Input 5 ANC C Close

6 Board Available Input 6 ANC C Open

7 AWC Pin Detection 7

0006h 0 CFB(F) Lock 000Bh 0 Conveyor1 Alarm

1 CFB(F) Unlock 1 Conveyor2 Alarm

2 CFB(F) Check 1 2 Conveyor3 Alarm

3 CFB(F) Check 2 3

4 CFB(R) Lock 4 AWC-axis ORG

5 CFB(R) Unlock 5

6 CFB(R) Check 1 6

7 CFB(R) Check 2 7

0007h 0 ANC A Close

1 ANC A Open

2 ANC B Close

3 ANC B Open

4 MXST2 R Position 1

5 MXST2 R Position 2

6 MXST2 L Position 1

7 MXST2 L Position 2
