Adjustable Screen Mount (ASM) Issue 2: July 2007
•
Remove Chase Rail
•
Replace ASM Cable
•
Replace chase rail and check chase to
table level
ASM Tasks
Issue 2: July 2007
table level
•
Adjust screen load sensor
•
Set screen change lever up and down
sensor positions
Objective 23: Complete activities in your workbook
Adjustable Screen Mount
(ASM)
Issue 2: July 2007
Screen Alignment Module
•
The screen alignment module consists of the
following sub-assemblies:
– 3x Screen Actuators (Xf, Xr, Y)
Issue 2: July 2007
– 2 x Chase Clamps
– 4 x Chase roller counter plates
– Chase clamp air regulator
– Dual Stepper drive cards (X1 & X3)
Replaced as complete assembly
