MODEL TCM-X200 0203-002 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 221 MB-6 50 1 630 103 8100 P ANEL(LCD) 1 696MB-1 10-501 50 2 630 105 1253 P ANEL ( CNL -SW ) 1 696MB-1 10-502 50 4 630 097 4690 P AN EL 6 696MB-1 …
MODEL TCM-X200
0211-003
220
ࡈࠖ࠳ࠠࡖ࠶ࠫࠞࡃㇱ FEEDER CARRIAGE COVER SECTION
Fig. MB-6 ᓟ㕙ᠲࡄࡀ࡞ Rear Operation Panel
Fig.MB-6
VIEW "A"
VIEW "B"
501
524
523
522
522
A
B
C
B
512
513
528
523
516
526
516
526
513
512
524
528
523
524
515
511
504
534
527
523
528
520
See Fig.MB-1
Key No.20
506
505
534
504
521
510
531
530
529
515
509
516
526
524
523
528
527
523
528
534
523
524
564
561
560
562
560
527
523
528
VIEW "C"
515
511
TCM-X200-003
4797A-003
565
563
551
552
.
553
.
555
554
555
556
502
533
558
557
.
559
MODEL TCM-X200
0203-002
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
221
MB-6
501 630 103 8100 PANEL(LCD) 1 696MB-110-501
502 630 105 1253 PANEL(CNL-SW) 1 696MB-110-502
504 630 097 4690 PANEL 6 696MB-110-504
505 630 097 4706 PANEL 1 696MB-110-505
506 630 098 4361 COVER(CABLE) 1 696MB-110-506
509 630 096 7579 BRACKET(SENSOR) 1 696MB-110-509
510 630 096 7562 BRACKET(ACTUATOR) 1 696MB-110-510
511 630 109 6049 BRACKET(SENSOR) 6 696MB-110-511
512 630 109 2607 BRACKET(ACTUATOR) 6 696MB-110-512
513 411 113 4708 SCR FLT 4X10 12 696MB-110-513
515 630 096 7685 SOLENOID 7 SQ4(YSOL5),SQ5(YSOL6),
SQ12(YSOL10),SQ10(YSOL12),
SQ13(YSOL11),SQ6(YSOL7),
SQ7(YSOL8) 696MB-110-515
516 630 095 7891 PLATE(ACUTUATOR) 7 696MB-110-516
520 411 051 2804 SCR TRS 4X8 4 696MB-110-520
521 411 043 6803 SCR PAN 5X12 18 696MB-110-521
522 630 000 7794 BOLT,HEX-SCT 4 696MB-110-522
523 411 141 6705 WASHER SPR 5 32 696MB-110-523
524 411 141 4107 WASHER V 5X10X1 18 696MB-110-524
526 411 002 4505 SCR FLT 5X8 14 696MB-110-526
527 630 001 0220 WASHER 14 696MB-110-527
528 630 000 7763 BOLT,HEX-SCT 28 696MB-110-528
529 630 000 7633 BOLT,HEX-SCT 2 696MB-110-529
530 411 141 2905 WASHER SPR 4 2 696MB-110-530
531 630 001 0213 WASHER 2 696MB-110-531
533 411 140 8304 SCR BIN 4X10 5 696MB-110-533
534 411 113 9109 SCR TRS 5X10 14 696MB-110-534
551 630 033 4609 SWITCH,BUTTON 1 SPB2 696MB-110-551
552 630 033 4586 DISPLAY ELEMENT 1 LED2 696MB-110-552
553 630 033 4593 ACCESSORY,SW 1 696MB-110-553
554 630 000 2515 SWITCH,BUTTON 1 SPB21 696MB-110-554
555 630 000 2713 SWITCH,BUTTON 2 SPB20(LED20),SPB22(LED22)
696MB-110-555
556 630 000 2744 SWITCH,BUTTON 1 SPB23(LED23) 696MB-110-556
557 630 000 0382 ACCESSORY,SW 1 696MB-110-557
558 407 035 4704 LED SLP-721F 1 LED21 696MB-110-558
559 630 085 9317 UNIT,DISPLAY 1 #FP-VM/SVGA-1 696MB-110-559
560 630 068 8375 ACCESSORY,CONN 2 696MB-110-560
561 630 093 8494 ASSY,CONNECTOR 1 SW5 696MB-110-561
562 630 089 0556 SOCKET 1 696MB-110-562
563 630 093 6445 ASSY,SWITCH,BUTTON 2 SPB7,SPB8 696MB-110-563
564 630 093 6407 ASSY,SWITCH,BUTTON 6 SPB31(LED31) - SPB36(LED36)
696MB-110-564
565 630 064 6320 NAME PLATE,NOTICE 2 696MB-110-565
