EDM V2.0 / Installation Manual Ausgabe 04/2012 Edition 6.3 Configuration Files NOTICE Use the “EDM Configuration Manger” (see 5.3 ) to ch ange the configuration if possi ble. Only the configuration files on the “EDM Conf…

EDM V2.0 / Installation Manual Ausgabe 04/2012 Edition

The User Specific Registry-Keys are sub-keys of:

"HKEY_CURRENT_USER\Software\Siemens SIPLACE\EDM"

Key Type Contents

Service String Language setting for the EDM Tool.

This key is generally *not* used by the EDM Service!

(The service runs as “SYSTEM” user previous EDM Versions used the

Key from: HKEY_USERS\S-1-5-18\Software\Siemens

SIPLACE\EDM\LanguageSettings. Due to access restrictions, this was not

configurable for a normal user).

Thus the EDM service uses the setting found in:

HKEY_LOCAL_MACHINE\SOFTWARE\Wow6432Node\Siemens

SIPLACE\EDM\LanguageSettings\Service).

Client String Language setting for the EDM Client.

Default: English. Can be changed in the EDM Client.

ClearingPool String Language setting for the Clearing Pool and Line Data

Transfer Manager.

Default: English. Can be changed in the Clearing Pool.

Configuration String Language setting for the Configuration. Default: English.

Can be changed in the Configuration Manager.

Table 6-4: EDM “LanguageSettings” (HKCU) entries in the Registry

NOTICE

Changing the Language with the “EDM Client” or the “EDM Configuration Manager” will

also change the Language for the “EDM Service” and “EDM Tool” on this computer.

Key Type Contents

ConfigCache Sub-Key A List of the configurations received by the configuration

server (used to find the current configuration on startup).

ForcedPull Sub-Key Data about the last data transfer (used by the “forced pull”

mode).

LanguageSettings Sub-Key User specific language settings see: Table 6-4

Performance Sub-Key Misc performance stats

PushMode Sub-Key User specific settings and History of the Data Transfer

Manager

Settings Sub-Key User specific settings and History for the “Clearing Pool”

Table 6-5: List of EDM Registry Keys (HKCU)

EDM V2.0 / Installation Manual Ausgabe 04/2012 Edition

6.3 Configuration Files

NOTICE

Use the “EDM Configuration Manger” (see 5.3) to change the configuration if possible.

Only the configuration files on the “EDM Configuration Server” should be edited. Any

change to a local (cached) copy of the configuration will be lost during the next

configuration synchronization (i.e. an application restart or configuration push).

This chapter describes the technical details of the EDM configuration files.

Hint: To edit a configuration that is not located in the EDM configuration path of the local machine

use the “Change root folder…” context menu in the “EDM Configuration Set Editor’s” Configuration-

Set Tree-View-Display. (If you want to paste a path instead of using the folder browser dialog,

“Shift-Click” on the “Change root folder“-Entry to show a text input-window.)

The EDM Configuration uses the following sub-folders of the ‘config’ folder:

Folder Contents

_cache Local (cached) copy of all configurations obtained from the EDM configuration

server. Contains a sub-folder with a name based on the EDM-Application the

configuration belongs to (e.g. the “_cache\EdmTool”).

Do not edit the files contained in this folder or any sub-folder, as they will be

overwritten the next time the corresponding application is restarted!

conversion Contains the transformation files the “EdmUpdater” uses to upgrade the

configurations from a previous EDM Version to the current version.

default This folder contains the most of the standard EDM configuration files. The files in

this folder are generally copied to create new configuration sets with different

settings.

global This folder contains the ‘global’ EDM configuration files. All EDM Configuration-Set

should reference the same global configuration files to ensure a consistent EDM

installation.

workflows This folder contains the predefined EDM workflows.

Table 6-6: EDM configuration folders

EDM 2.0 provides a role-based centralized configuration. The EDM configuration server always

uses the “EdmConfiguration.xml” file in the “ConfigDir” to load its own configuration.

All other EDM applications receive their configuration data based on a role definition (currently

based on application-, user-, host-name and type). The matching relies on the “RoleConfig” entry in

the configuration set used by the configuration server (typically “global\RoleConfig.xml”).

By default, all EDM Applications use the same configuration as the EDM Configuration server (the

standard RoleConfig only contains a single entry that matches any role and points to the default

EdmConfiguration.xml file).

CAUTION

Please keep in mind, that any change to a configuration file referenced by the EDM

configuration server configuration set (EdmConfiguration.xml) will be applied

immediately. For example changing the “configurationServerPort” setting will cause the

configuration server to change its port to the new value – making it unreachable for all

existing clients.

EDM V2.0 / Installation Manual Ausgabe 04/2012 Edition

EDM 2.0 uses the following configuration files (some are new others just moved to another folder):

Folder File (Editor) Contents

. EdmConfiguration.xml

(EDM Configuration Sets)

Default EDM configuration set (always used by the EDM

configuration server).

global MachineConfig.xml

(Line Settings)

This configuration contains the data about all EDM computers.

Especially it contains the Line-Alias definition and SIPLACE-

Line-Assignments for all EDM Hosts. See 0 for details.

Contains the entries previously found in the

<machineAliasNames> section of the EDM.config file.

The format of the entries has changed!

global RoleConfig.xml

(Roles)

This file contains the mapping from EDM Line to

ConfigurationSet.

Note: The Display order is determined by the ‘index’ attribute

and not the order in the file.

default CommentConfig.xml

(Comment Categories)

Contains most of the settings previously found in the

<commentCategories> section of the EDM.config.

Note: The Display order is determined by the ‘index’ attribute

and not the order in the file.

default DataTransferConfig.xml

(Data Transfer (Push))

Settings used by the Data Transfer Manager when pushing

data. See 6.3.7 for details. The file just moved from the root

configuration folder to the ‘default’ folder.

default NotificationFilterConfig.xml

(

Notifications / Filtering – Notification Filter)

Contains the EDM Notification filtering configuration. The file

just moved from the root configuration folder to the ‘default’

folder.

default ClearingPoolImportFilterConfig.xml

(

Notifications / Filtering – Notification Filter)

Contains the EDM Direct-Import rules. The file just moved

from the root configuration folder to the ‘default’ folder.

default ClearingPoolRejectFilterConfig.xml

(

Notifications / Filtering – Notification Filter)

Contains the EDM Auto-Reject rules. The file just moved from

the root configuration folder to the ‘default’ folder.

default EmailConfig.xml &

EmailNotificationFilterConfig.xml

(Notifications / Filtering – EMail)

Contains the EDM Email notification rules. The files just

moved from the root configuration folder to the ‘default’ folder.

default SystemConfig.xml

(Advanced Settings – System Settings)

Contains most of the settings previously found in the

<appSettings> section of the EDM.config - See 6.3.3 for

details.

default CustomConfig.xml

(Advanced Settings – Custom Settings)

Contains the entries previously found in the <customConfig>

section of the EDM.config file.

Note: The values may be accessed programmatically via:

InternalConfig.Instance.EdmSettings.CustomSettings.* or

InternalConfig.Instance.GetCustomData(…)

default RequestConfig.xml

(Advanced Settings – Requests)

Contains the entries previously found in the

<requestCommandConfig> section of the EDM.config file.

Enter settings used by custom workflows here.

Note: If your workflow uses custom actions, they must be

entered in this file to be usable by EDM.

default DisplayConversionConfig.xml Contains a list of Properties that need to be converted before

display. The file just moved from the root configuration folder

to the ‘default’ folder.
