SIPLACE Pro V12.1 / Software Version Description Ausgabe 05/2015 Edition
5
1 Introduction
SIPLACE® Pro is the programming system for SIPLACE© placement machines under Windows.
The placement programs for the placement lines are prepared, generated and optimized with
SIPLACE Pro.
1.1 System Overview
The SIPLACE Pro programming system consists of the following subsystems:
Figure 1-1:System overview
SIPLACE Pro saves all data in a database (Microsoft SQL Server). All clients, such as the Desk,
communicate via the Business Layer with the SIPLACE Pro Server.
The system installation can be distributed across several computers.
SIPLACE Pro V12.1 / Software Version Description Ausgabe 05/2015 Edition
6
2 Scope of Delivery
2.1 Packages
● SIPLACE Pro Basic License V12.1, item no. [00117802-xx] contains:
– 1 SIPLACE Pro Factory License (without connection to the SIPLACE stations)
● SIPLACE Pro Media Package V12.1, item no. [00117801-xx] contains:
– Software CD-ROM with SIPLACE Pro 12.1
– Software CD-ROM with OIS application 12.1, item no.: [00117809-xx]
– Software DVD SIPLACE NET Support Media Version 2.1, item no.: [00117951-xx]
– Software Installation Manual SIPLACE Pro 12.1, (English) item no.: [00197629-xx]
– Software Installation Manual SIPLACE LED Pairing 2.1, (English) item no.: [00197283-xx]
● SIPLACE Pro Language Package V12.1, item no.: [00117804-xx]
– Software CD-ROM (language pack)
– Software Installation Manual SIPLACE Pro 12.1 (English) Language Pack, item no.:
[00197629-xx]
To Support Media DVD:
Please use the Navigation Guide button of the Support Media Launcher to navigate
through the documentation.
The navigation guide and all related documents are available on the Support Media
