SIPLACE Pro V12.1 / Software Version Description Ausgabe 05/2015 Edition
8
2.3 Licenses
The available licenses are listed in the following table.
License
Type
Factory Single Floating Lines
SIPLACE Pro Server / Desk (includes OIS / SIS)
SIPLACE Pro – Machine Connection
SiCluster
SiCluster Professional
SiCluster Professional – Machine Connection
SiCluster Multiline – Machine Connection
Split Table Mode – Machine Connection
SIPLACE Traceability – Machine Connection
SIPLACE Vision Teach Station
Whispering Down The Line
Automatic Program Download (PCB-Barcode)
Station Wise Download – Machine Connection
Borrow Performance – Machine Connection
Heavy Board Option – Line Connection
Reading Barcode recognition with PCB Camera
Notice: This license is required for each station in the line
or, alternatively to this, an installed barcode reader.
Alternative Components
Random Setup
Whispering of Barcodes
Long Board Option – Machine Connection
Notice: This license is required for each station in the line.
SIPLACE LED Pairing – Machine Connection
Table 2-2: Available Licenses
SIPLACE Pro V12.1 / Software Version Description Ausgabe 05/2015 Edition
9
Definition of the License Types
Factory
This license type is valid for the entire production run and is not assigned to a license server.
Single
This license type is valid in connection with a (single) station.
Floating
This license type is fetched from a license server by the application and then released again
when the application is terminated. However, the number of licenses on the license server is
limited.
Lines
This license type is assigned to the placement line.
SIPLACE Pro V12.1 / Software Version Description Ausgabe 05/2015 Edition
10
3 Prerequisites
NOTICE
System requirements
The Support Media DVD included in the installation package checks the necessary
system requirements of your system and installs these. Amongst others e.g. Microsoft
.NET Framework, the License Manager and the Error Reporting tool.
The use of the Support Media V2.1 is obligatory.
The system requirements (supported operating systems and database variants) and an
overview of the interoperable products can be found in the SIPLACE Support Media
Software Version Description, item no. [00197793-xx].
SIPLACE Pro requires an NTFS partition for the installation. FAT or FAT32 file systems are not
supported.
3.1 Supported Station Software Versions and Machine Types
Station Software
Version
Machine Types
708 DX-series: DX1, DX2, DX4
SX-series: SX1/SX2, SX1/SX2 V2, SX4
X-series: X2, X3, X4, X4i
X-series S X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA3, CA4
707 DX-series: DX1, DX2, DX4
SX-series: SX1/SX2, SX1/SX2 V2, SX4
X-series: X2, X3, X4, X4i
X-series S: X2 S, X3 S, X4 S, X4 S micron,
X4i S, X4i S micron
CA-series: CA3, CA4
605 D-series: D1, D2, D3, D4
X-series: X2, X3, X4
505 S23HM, S25HM, HS50, HS60, HF, HF/3
408/101 CS, CF
407 S20, F4, F5, S23, F5HM
Table 3-1: Supported station software versions and machine types
