vi
Before starting work
c
CAUTION
HIGH VOLTAGE!
Electrical shock hazard
23001-5E-2C
c
CAUTION
Use caution since electrical shocks might occur from touching or coming in contact with the power supply section inside
the panel.
HOT!
Possible burns if touched
23001-5E-2D
c
CAUTION
The motor becomes extremely hot during and shortly after operation, so do not touch it!
Possible loss of eyesight
LASER BEAM
Do not stare into laser beam!
Max. output:1 mW, Pulse width: 1ms max.
Semiconductor laser (wavelength: 685nm)
Class 2 laser product
LASER BEAM EXIT
23001-5E-2E
c
CAUTION
Looking directly into the laser beam may cause loss of eyesight.
1. Safety
vii
Before starting work
1. Safety
DON'T
TOUCH
Do not touch camera unit.
DO NOT TOUCH
23001-5E-2F
c
CAUTION
Do not touch the camera unit or apply impacts since this will adversely affect component mounting operation.
Make correct connections.
23001-5E-2K
c
CAUTION
Wrong connections or wiring methods other than specified might damage the machine. Always make correct connections
by complying with the specified wiring methods.
Do not use any solvent other than specified.
23001-5E-2L
c
CAUTION
Using other than the specified solvents might damage the machine or create a fire hazard.
viii
Before starting work
1. Safety
1.4 Warning label positions
Warning labels with information needed to use the machine safely and correctly are affixed to the machine and
peripheral equipment. Be sure to comply with the instructions on these warning labels.
Warning labels
Attachment positions (1)
WARNING
CLOSE COVER WHILE OPERATING
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ TSF1 open/close cover
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Conveyor cover
■ Conveyor cover
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of TSF1 open/close cover
DON'T
TOUCH
■ Fiducial camera ■ Multi-vision camera
DO NOT TOUCH
23003-5E-20
