Chapter 2 Daily maintenance items T able of Contents 1. Checking the nozzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 1.1 Check with softw are . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…
1-8
1
Maintenance
2.3 Required tools
Prepare the following tools and items necessary for maintenance.
Name Description
Tool list
Option
Large, small
Large, small
#0, #1
1 set
Used to replace ejector filters.
Used to supply turbine oil (VG32).
Used to apply grease to an axis, etc.
Used to blow air onto a nozzle, etc.
Used to clean nozzles.
Phillips screwdriver
Slotted screwdriver
Phillips precision screwdriver
Hex wrench set
Tweezers
Nozzle holder lubricating syringe
Grease gun
Air blow gun
Ultrasonic cleaner
45107-5E-20
Name Description
Other tool list
Used to lubricate ball screws and guides other than head assembly.
Used to lubricate nozzle holders and nozzles.
Use cleaning paper that does not leave dust, grit or residue.
Use IPA (iso-propyl alcohol) or ethanol.
Used for cleaning spline shaft.
Used for cleaning nozzle holders.
Used for marking when replacing conveyor belt.
Used to clean half mirror and lighting unit.
Used to clean the lens of multi-vision camera.
Used to clean the camera lighting unit.
Grease (lithium-based grease)
Turbine oil (VG32)
Cleaning paper
Cleaning alcohol
Paper cup or tray
Film container or equivalent
Marker pen
Cotton swab stick
Lens cleaner
Lens blow brush
45108-5E-20
2. Preparing for maintenance tasks
Chapter 2
Daily maintenance items
Table of Contents
1. Checking the nozzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
1.1 Check with software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
1.2 Checking the nozzles visually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2. Checking the nozzle leaf springs . . . . . . . . . . . . . . . . . . 2-4
3. Checking the nozzle spring action . . . . . . . . . . . . . . . . . 2-5
4. Cleaning the feeder plate . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
5. Cleaning the camera lighting unit . . . . . . . . . . . . . . . . . . 2-7
