viii
Before starting work
1. Safety
1.4 Warning label positions
Warning labels with information needed to use the machine safely and correctly are affixed to the machine and
peripheral equipment. Be sure to comply with the instructions on these warning labels.
Warning labels
Attachment positions (1)
WARNING
CLOSE COVER WHILE OPERATING
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ TSF1 open/close cover
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Conveyor cover
■ Conveyor cover
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of TSF1 open/close cover
DON'T
TOUCH
■ Fiducial camera ■ Multi-vision camera
DO NOT TOUCH
23003-5E-20
ix
Before starting work
1. Safety
Warning labels
Attachment positions (2)
■ Main power connection
section
■ Rear panel
■ Switching power supply
(inside of panel)
■ Motor section (inside of cover)
■ Signal cable connector
■ Front panel
■ Conveyor entrance/exit opening
WARNING
Do not put In
hand through
openIng.
MovIng parts can
pInch hand.
23004-5E-20
x
Before starting work
2. Warranty
The machine you have purchased is warranted against malfunctions as described below.
■ Warranty Coverage
If any failure or defects are found in this machine due to poor workmanship within the warranty period (one year or 2400
hours of operation whichever comes first), we will repair or replace the defective parts free of charge.
■ Warranty Period
The warranty period ends when any of the following applies:
1. After one year has elapsed from the time of installation of the machine.
2. After 2400 hours of operation.
■ Items not covered by the warranty
The warranty does not cover any of the following conditions:
1. Defects or trouble as a result of deterioration due to age or wear
Example: Normal discoloration of painted or plated surfaces, wear of consumable parts, etc.
2. Incidents associated with sensory perceptions which have no bearing on the quality or function of the machine
Example: Signal sounds emitted by the controller, rotating sounds of the motor, etc.
3. Damage as a result of user environment
Example: Impurities in the air supply, dust, debris and oil mist in the machine
■ Exception to warranty repairs
Warranty repairs shall not apply if failure or defects are caused by the following:
1. Earthquakes, typhoons, floods, lightning, accidents or fires and other natural or man-made disasters.
2. Modifications not approved by i-PULSE or its distributors.
3. Use of non-genuine parts, greases or lubricants.
4. Lack of proper maintenance and inspection procedures.
5. Maintenance handled by someone other than the approved distributors.
6. Change of the machine installation level due to poor foundations or harsh environment.
7. Machine was moved to another location after installation or modified to change specifications.
8. Defective parts replaced free of charge were not returned to the specified destination within 30 days.
■ Note on network connections
A precondition for machine network connections is that such connections will be used in closed networks comprised of a
machine and an off-line PC. The customer must take responsibility for connections to company in-house networks and to
external networks. Please acknowledge that i-PULSE can bear absolutely no responsibility for networks configured by
other than just a machine and off-line PC nor can accept responsibility for problems occurring due to network settings and
connections.
