viii Before starting work 1. Safety 1.4 Warning label positions Warning labels with information needed to use the machine safely and correctly are affixed to the machine and peripheral equipment. Be sure to comply with t…
vii
Before starting work
1. Safety
DON'T
TOUCH
Do not touch camera unit.
DO NOT TOUCH
23001-5E-2F
c
CAUTION
Do not touch the camera unit or apply impacts since this will adversely affect component mounting operation.
Make correct connections.
23001-5E-2K
c
CAUTION
Wrong connections or wiring methods other than specified might damage the machine. Always make correct connections
by complying with the specified wiring methods.
Do not use any solvent other than specified.
23001-5E-2L
c
CAUTION
Using other than the specified solvents might damage the machine or create a fire hazard.
viii
Before starting work
1. Safety
1.4 Warning label positions
Warning labels with information needed to use the machine safely and correctly are affixed to the machine and
peripheral equipment. Be sure to comply with the instructions on these warning labels.
Warning labels
Attachment positions (1)
WARNING
CLOSE COVER WHILE OPERATING
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Safety cover
(open/close cover)
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ TSF1 open/close cover
WARNING
DO NOT TOUCH THIS SWITCH
MOVING MACHINE MAY CAUSE INJURY
■ Conveyor cover
■ Conveyor cover
WARNING
CLOSE COVER WHILE OPERATING
■ Inside of TSF1 open/close cover
DON'T
TOUCH
■ Fiducial camera ■ Multi-vision camera
DO NOT TOUCH
23003-5E-20
ix
Before starting work
1. Safety
Warning labels
Attachment positions (2)
■ Main power connection
section
■ Rear panel
■ Switching power supply
(inside of panel)
■ Motor section (inside of cover)
■ Signal cable connector
■ Front panel
■ Conveyor entrance/exit opening
WARNING
Do not put In
hand through
openIng.
MovIng parts can
pInch hand.
23004-5E-20
