Support Media 2.0 12/2014 Edition
9
2.2 Products of Release 70 (R70)
Product
Release 70
SIPLACE Board Gate Keeper
1.2
SIPLACE EDM
3.0
SIPLACE Explorer
3.0
SIPLACE Feeder Manager
2.4
SIPLACE LED Pairing Controller
1.0 SP2
SIPLACE License Manager
4.0
SIPLACE Line Monitor
2.1
SIPLACE Material Manager
1.1
SIPLACE OIB
4.0
SIPLACE OIS/SIS
12.0
SIPLACE Order Manager
1.0
SIPLACE Performance Monitor
1.4
SIPLACE Pro
12.0
SIPLACE Setup Center
7.0
SIPLACE Station Software
708
SIPLACE Support Media
2.0
SIPLACE Traceability
4.0
Support Media 2.0 12/2014 Edition
10
3 Compatibility
Figure 3-1: Compatibility of interoperable products
SQL 2008R2 SP 2 Express
SQL 2008R2 SP 2 Express x64
SQL 2012 SP 2 CU2 Express
SQL 2012 SP 2 CU2 Express x64
SQL Server 2008R2 SP 2 x64
SQL Server 2012 SP 2 CU2 x64
Windows Server 2008 R2 SP 1 x64
Windows Server 2012 R2 x64
Windows 7 SP 1 x86
Windows 7 SP 1 x64
Windows 8.1 x64
Microsoft .Net Framework 3.5 Service Pack 1
Microsoft .Net Framework 4.0
Sun JRE 7.0.670.1
Tomcat 7.0.55
SIPLACE BoardGateKeeper 1.2 n n n n n n x x x x x n x n n
SIPLACE EDM 3.0 x x x x x x x x x x x n x n n
SIPLACE Explorer 3.0 x x x x x x x x x x x n x x x
SIPLACE FM 2.4 Client n n n n n n x x x x x n x n n
SIPLACE FM 2.4 Line Console n n n n n n x x x x x n x n n
SIPLACE FM 2.4 Maintenance Server n n n n n n x x x x x n x n n
SIPLACE FM 2.4 Server x x x x x x x x x x x n x n n
SIPLACE LED Pairing Controller 1.0 SP2 n n n n n n x x x x x n x n n
SIPLACE License Manager 4.0 n n n n n n x x x x x x x n n
SIPLACE Line Monitor 2.1 GUI n n n n n n x x x x x x n n n
SIPLACE Line Monitor 2.1 Server n n n n n n x x x x x x n n n
SIPLACE Material Manager 1.1 - - - - x x x x - - - x x n n
SIPLACE OIB 4.0 Infrastructure - Adapter n n n n n n x x x x x n x n n
SIPLACE OIB 4.0 Infrastructure - Client API n n n n n n x x x x x n x n n
SIPLACE OIB 4.0 Infrastructure - Core Client n n n n n n x x x x x n x n n
SIPLACE OIB 4.0 Infrastructure - Core Server x x x x x x x x x x x n x n n
SIPLACE OIS/SIS 12.0 Client n n n n n n x x x x x x x n n
SIPLACE OIS/SIS 12.0 Server x x x x x x x x x x x x x n n
SIPLACE Order Manager Client 1.0 n n n n n n x x x x x n x n n
SIPLACE Order Manager Server 1.0 - - - - x x x x - - - n x n n
SIPLACE Performance Monitoring 1.4 Business x x x x x x x x x x x n x n n
SIPLACE Performance Monitoring 1.4 Web GUI n n n n n n x x x x x n x n n
SIPLACE Performance Monitoring 1.4 WebService n n n n n n x x x x x n x n n
SIPLACE Pro 12.0 Client n n n n n n x x x x x n x n n
SIPLACE Pro 12.0 Server x x x x x x x x x x x n x n n
SIPLACE Setup Center 7.0 Client n n n n n n x x x x x n x n n
SIPLACE Setup Center 7.0 Server x x x x x x x x x x x n x n n
SIPLACE Studio 2.0 n n n n n n x x x x x n x n n
SIPLACE Traceability Monitor 4.0 n n n n n n x x x x x n x n n
SIPLACE Traceability Service 4.0 x x x x x x x x x x x n x n n
n
not needed (nicht benötigt)
x needed and supported (benötigt und unterstützt)
-
needed but not supported (benötigt aber nicht unterstützt)
note:
the above mentioned compatibilities are only valid if not installed on a Station Computer
Support Media 2.0 12/2014 Edition
11
4 Functionality
4.1 Changes
The following changes have been made:
Build for Release 70
Removed support for obsolete operating systems and SQL database versions
Removed obsolete prerequisites required by certain OS only
Removed profiles supporting obsolete OS/SQL database versions only
Adapted existing profiles and removed obsolete OS/SQL database versions
Updates as required for Material Setup Assistant (also released separately in Support
Media 1.16 SP 1)
Minor improvements and fixes
4.2 Updates
New prerequisites:
Oracle Java 7 Update 67
SIPLACE Error Reporter Service 1.7
SIPLACE License Manager 4.0
SIPLACE Operation Manager 1.8
SIPLACE Studio 2.0
SIPLACE YATS 7.0
Apache Tomcat 7.0.55
Microsoft Visual C++ 2013 Update 2 redistributables
Removed prerequisites and deliveries (space or redistribution restrictions):
Due to cancelled support of certain operating systems and SQL database versions, some
packages have been removed to save disk space. For a more detailed list of contained
packages, please see chapter 4.3.
Added/updated documentation:
Support Media 2.0 Installation Manual (this document)
SIPLACE License Manager 4.0 Installation Manual
4.3 Content of DVD1
CAUTION
Legal changes regarding Microsoft components
Due to legal changes it is not possible anymore to redistribute all Microsoft
components as in versions before release SuP40 of the Support Media. We now
offer a download feature to get the required Microsoft components online.
