Support Media 2.0 12/2014 Edition
16
detect, if .Net Framework is missing and asks you to install it using the
appropriate Analyzer Profile from the profile group SIPLACE Net.
If you get this message, step back to the Product Selection page and select the
appropriate profile in SIPLACE Net\.Net Framework stand- alone setups only
(deselect previously selected profiles) to install .Net Framework 3.5 SP 1.
The following picture shows you an example.
Figure 4-3: Screenshot of Support Media Download tool
NOTICE
Complete download not always possible
Depending on the products you selected, your operating system and its
configuration, the availability of web-based links, etc. there might be software
packages missing, which can’t be downloaded automatically.
You will get an appropriate warning message, depending on your situation (e.g.
all missing software packages are not downloadable, only a part of missing
packages are not downloadable).
Please use the Download and install manually option if you encounter this
problem. It will show you alternative hints and links on how to get/install the
missing packages.
When the download of missing software packages completed successfully and no other
packages are missing, the Install button will be visible and the Analyzer will allow
continuing automatic preparation of your computer.
4.4.3 Download Offline option
After you selected the Download Offline option, Analyzer will ask for the location to store
the Download List as shown in the following picture.
Support Media 2.0 12/2014 Edition
17
Figure 4-4: Analyzer asking for the location to store the Download List
NOTICE
Default Download List location and naming
The default location for the Download List is
<MyDocumentsFolder>\PrerequisiteAnalyzer_ExternalDownloadList_<Computer
Name>.xml.
Since this list contains information specific to the computer, the name of the
download list contains the computer name for which it was created. This will help
you identifying it.
After you defined the location of the Download List, the Download List and the Support
Media Download Tool (“SUPPORT_MEDIA_DOWNLOAD.EXE”) will be saved to the
specified location and you will see a new Windows Explorer window appearing with the
Download List selected, to simplify finding the files created.
After that, the following message will be displayed.
Figure 4-5: Export finished message of Analyzer
► Click the Yes button if you want to close Analyzer later until you downloaded all files
on the other computer.
► Click the No button to step back to the previous options dialog, allowing you to select
an alternative Additional Software Search Folder containing all missing packages.
Support Media 2.0 12/2014 Edition
18
NOTICE
Complete download not always possible
As with the Download online option, there might be cases where software
packages are missing which can’t be downloaded automatically.
You will get an appropriate warning message, depending on your situation (e.g.
all missing software packages not downloadable, only a part of missing
Packages not downloadable).
Please use the Download and install manually option if you encounter this
problem. It will show you alternative hints and links on how to get/install the
missing Packages.
► Transfer the files to another computer with access to the Internet (e.g. using an USB
drive).
► On the computer with web- access, execute the
SUPPORT_MEDIA_DOWNLOAD.EXE tool and select the appropriate download list
using the option File – Open Siplace Prerequisite File.
► After that, the Download Tool will ask for a folder to store downloads. Select an
appropriate location.
NOTICE
Subfolder for download structure required
Prerequisite Analyzer only detects downloaded files, if the relative directory
structure to all Tools and Updates remains consistent. To ensure this, use a new
custom subfolder to store all download content. When transferring to the offline
computer, only this folder with all content needs to be copied.
► Click the Start button to initiate the download.
► After you completed the download of all packages successfully, close the Download
Tool.
Transfer the contents of the download folder back to the computer you tried to prepare:
► On the computer you tried to prepare, start Prerequisite Analyzer and when asked,
click the option to select a local Additional Software Search folder.
► After you specified the search folder, click the button Copy offline files to Search
Folder.
