Support Media 2.0 12/2014 Edition 18 NOTICE Complete do w nload not a lways possible As with the Downl oad online option , there migh t be cases w here software packages are missi ng which can’ t be dow nloaded automatic…
Support Media 2.0 12/2014 Edition
17
Figure 4-4: Analyzer asking for the location to store the Download List
NOTICE
Default Download List location and naming
The default location for the Download List is
<MyDocumentsFolder>\PrerequisiteAnalyzer_ExternalDownloadList_<Computer
Name>.xml.
Since this list contains information specific to the computer, the name of the
download list contains the computer name for which it was created. This will help
you identifying it.
After you defined the location of the Download List, the Download List and the Support
Media Download Tool (“SUPPORT_MEDIA_DOWNLOAD.EXE”) will be saved to the
specified location and you will see a new Windows Explorer window appearing with the
Download List selected, to simplify finding the files created.
After that, the following message will be displayed.
Figure 4-5: Export finished message of Analyzer
► Click the Yes button if you want to close Analyzer later until you downloaded all files
on the other computer.
► Click the No button to step back to the previous options dialog, allowing you to select
an alternative Additional Software Search Folder containing all missing packages.
Support Media 2.0 12/2014 Edition
18
NOTICE
Complete download not always possible
As with the Download online option, there might be cases where software
packages are missing which can’t be downloaded automatically.
You will get an appropriate warning message, depending on your situation (e.g.
all missing software packages not downloadable, only a part of missing
Packages not downloadable).
Please use the Download and install manually option if you encounter this
problem. It will show you alternative hints and links on how to get/install the
missing Packages.
► Transfer the files to another computer with access to the Internet (e.g. using an USB
drive).
► On the computer with web- access, execute the
SUPPORT_MEDIA_DOWNLOAD.EXE tool and select the appropriate download list
using the option File – Open Siplace Prerequisite File.
► After that, the Download Tool will ask for a folder to store downloads. Select an
appropriate location.
NOTICE
Subfolder for download structure required
Prerequisite Analyzer only detects downloaded files, if the relative directory
structure to all Tools and Updates remains consistent. To ensure this, use a new
custom subfolder to store all download content. When transferring to the offline
computer, only this folder with all content needs to be copied.
► Click the Start button to initiate the download.
► After you completed the download of all packages successfully, close the Download
Tool.
Transfer the contents of the download folder back to the computer you tried to prepare:
► On the computer you tried to prepare, start Prerequisite Analyzer and when asked,
click the option to select a local Additional Software Search folder.
► After you specified the search folder, click the button Copy offline files to Search
Folder.
Support Media 2.0 12/2014 Edition
19
The following window appears.
Figure 4-6: Source folder selection dialog for copying download files back to local Search Folder
► Inside the Browse For Folder window, ensure that you have a valid connection to the
location of your download files (e.g. USB drive, network path).
NOTICE
Windows Vista or newer: User Account Control complicates accessing
network drives in Prerequisite Analyzer
Although the dialog supports accessing network drives, you may have problems
accessing network drives you mapped in Windows Explorer within Prerequisite
Analyzer because of Windows distinguishing between mapped drives during
normal user sessions and admin sessions.
► To access the network drive you mapped during a user session, right- click
on “My Network Places” inside the window, choose “map network drive” and re-
map the network drive inside the session of Prerequisite Analyzer.
► Select the appropriate location or enter the path to the location of your download files
as shown in the picture above.
► Click OK to continue.
Prerequisite Analyzer will now copy the downloaded files from the offline folder to the local
Software Search folder you specified before.
