Support Media 2.0 12/2014 Edition
34
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
C:\Program Files
(x86)\Microsoft
SQL
Server\90\Shared\s
qlbrowser.exe>
Port (W32Time
Service)
SIPLACE Port UDP
123 (W32Time
Service)
N/A
N/A
Inbound
UDP
123
Rule for allowing the Windows Time
Service to host time for other
computers
Application (Tomcat
5.x)
SIPLACE
Tomcat5.exe (TCP In)
<Path to
Tomcat5.exe of
Tomcat Service>
N/A
Inbound
TCP
ANY
Rule for allowing remote access to
Tomcat5 Webserver via TCP
Application (Tomcat
7.x)
SIPLACE
Tomcat7.exe (TCP In)
<Path to
Tomcat7.exe of
Tomcat Service>
N/A
Inbound
TCP
ANY
Rule for allowing remote access to
Tomcat7 Webserver via TCP
5.1.2 SIPLACE Pro Server
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
COM + Application
SIPLACE Pro Server
(DCOM In)
%system32%\system32\
dllhost.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Server
via DCOM protocol
for 32 Bit host system
COM + Application
SIPLACE Pro Server *
(DCOM In)
%system32%\SysWOW
64\dllhost.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Server
via DCOM protocol
for 64 Bit host system
5.1.3 Desk Info Service (DeskInfo.exe)
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Pro DeskInfo
Service (SOAP TCP In)
%Program Files%\
SIPLACE\SIPLACE
Pro \DeskInfo.exe
N/A
Inbound
TCP
3375
Collects info about open
objects in SIPLACE Pro
applications to serialize them
when creating SIPLACE Pro
Error Reports
Support Media 2.0 12/2014 Edition
35
5.1.4 VtsAdapter (VtsAdapter.exe)
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Vision
Teach Station (TCP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\VtsAdapter.exe
N/A
Inbound
TCP
47310 -
47340
Allow TCP inbound
communication of VtsAdapter
Application
SIPLACE Vision
Teach Station (UDP
In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\VtsAdapter.exe
N/A
Inbound
UDP
47310 -
47340
Allow UDP inbound
communication of VtsAdapter
5.1.5 SIPLACE Pro Line Control
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Line Control
(SOAP HTTP Out)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
TCP(HTTP)
49001
Allow access to the
Station via HTTP
protocol
Application
SIPLACE Line Control
(SOAP TCP Out)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
TCP
49002
Allow access to the
Station via TCP
protocol
Application
SIPLACE Line Control
(SOAP HTTP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
<Don’t filter
servicename –
doesn’t work>
Inbound
TCP(HTTP)
49003
Allow access to the
Line Control Server via
HTTP protocol
Application
SIPLACE Line Control
(SOAP TCP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
<Don’t filter
servicename –
doesn’t work>
Inbound
TCP
49004
Allow access to the
Line Control Server via
TCP protocol
Application
SIPLACE Line Control
(SOAP HTTP Out to
Setup Center)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
HTTP
49041
Allow access to the
Setup Center via
HTTP protocol
net use
SIPLACE Line Control
(net use)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
N/A
Outbound
NetBios
Protocol
139 / 445
Used to write files onto
some stations via
network share
Note: this rule is not
Support Media 2.0 12/2014 Edition
36
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
explicitly required – the
build in file and printer
sharing rules are used
instead
COM + Application
SIPLACE Line Control
(DCOM In)
%system32%\system
32\dllhost.exe
(for %Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 32
bit host system
COM + Application
SIPLACE Line
Control* (DCOM In)
%system32%\SysW
OW64\dllhost.exe
(for %Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 64
bit host system
COM + Application
SIPLACE Line Control
Server (RPC In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control Server
COM + Application
SIPLACE Line Control
Dispatcher (RPC In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control
Dispatcher
You can freely configure network shares in the Line Control GUI Configuration (SIPLACE OS and Recipe Analyzer), which will be used by Line Control.
5.1.6 SetupCenter (SetupCenter.exe and SetupCenterServer.Service.exe)
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE Setup Center Server
%ProgramFiles%\
SIPLACE\
SetupCenterService\
SetupCenterServer.Ser
vice.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication to
SetupCenterServer.Servi
ce.exe
Application
SIPLACE Setup Center
%ProgramFiles%\
N/A
Inbound
ANY
ANY
Allow inbound
