Support Media 2.0 12/2014 Edition 36 Rules Name Of The Rule Path Service Name Direction Protocol(s) Ports Purpose explicitly req uired – the build in file and printer sharing rules are used instead COM + Application SIPL…

100%1 / 44
Support Media 2.0 12/2014 Edition
35
5.1.4 VtsAdapter (VtsAdapter.exe)
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Vision
Teach Station (TCP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\VtsAdapter.exe
N/A
Inbound
TCP
47310 -
47340
Allow TCP inbound
communication of VtsAdapter
Application
SIPLACE Vision
Teach Station (UDP
In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\VtsAdapter.exe
N/A
Inbound
UDP
47310 -
47340
Allow UDP inbound
communication of VtsAdapter
5.1.5 SIPLACE Pro Line Control
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE Line Control
(SOAP HTTP Out)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
TCP(HTTP)
49001
Allow access to the
Station via HTTP
protocol
Application
SIPLACE Line Control
(SOAP TCP Out)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
TCP
49002
Allow access to the
Station via TCP
protocol
Application
SIPLACE Line Control
(SOAP HTTP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
<Don’t filter
servicename –
doesn’t work>
Inbound
TCP(HTTP)
49003
Allow access to the
Line Control Server via
HTTP protocol
Application
SIPLACE Line Control
(SOAP TCP In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
<Don’t filter
servicename –
doesn’t work>
Inbound
TCP
49004
Allow access to the
Line Control Server via
TCP protocol
Application
SIPLACE Line Control
(SOAP HTTP Out to
Setup Center)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
<Don’t filter
servicename –
doesn’t work>
Outbound
HTTP
49041
Allow access to the
Setup Center via
HTTP protocol
net use
SIPLACE Line Control
(net use)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
N/A
Outbound
NetBios
Protocol
139 / 445
Used to write files onto
some stations via
network share
Note: this rule is not
Support Media 2.0 12/2014 Edition
36
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
explicitly required – the
build in file and printer
sharing rules are used
instead
COM + Application
SIPLACE Line Control
(DCOM In)
%system32%\system
32\dllhost.exe
(for %Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 32
bit host system
COM + Application
SIPLACE Line
Control* (DCOM In)
%system32%\SysW
OW64\dllhost.exe
(for %Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe)
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow access to the
SIPLACE Pro Line
Control Server via
DCOM protocol for 64
bit host system
COM + Application
SIPLACE Line Control
Server (RPC In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control Server
COM + Application
SIPLACE Line Control
Dispatcher (RPC In)
%Program
Files%\SIPLACE\SIP
LACE
Pro\LCDSVR.exe
N/A
Inbound
TCP
RPC
Dynamic
Ports
Allow RPC access to
Line Control
Dispatcher
You can freely configure network shares in the Line Control GUI Configuration (SIPLACE OS and Recipe Analyzer), which will be used by Line Control.
5.1.6 SetupCenter (SetupCenter.exe and SetupCenterServer.Service.exe)
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
Service
SIPLACE Setup Center Server
%ProgramFiles%\
SIPLACE\
SetupCenterService\
SetupCenterServer.Ser
vice.exe
N/A
Inbound
ANY
ANY
Allow inbound
communication to
SetupCenterServer.Servi
ce.exe
Application
SIPLACE Setup Center
%ProgramFiles%\
N/A
Inbound
ANY
ANY
Allow inbound
Support Media 2.0 12/2014 Edition
37
Rules
Name Of The Rule
Path
Service Name
Direction
Protocol(s)
Ports
Purpose
SIPLACE\
SetupCenter\SetupCent
er.exe
communication to
SetupCenter.exe
5.1.7 Resources used by SIPLACE License manager application
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Application
SIPLACE License
Manager Server (SOAP
In)
%Program
Files%\SIPLACE\SIPLACE
Licensemanager2\
Asm.As.License.Host.exe
N/A
Inbound
TCP
1410
Allow access to the
SIPLACE
LicenseManager Server
via HTTP protocol
5.1.8 SIPLACE EDM
Rules
Name Of The Rule
Path
Service
Name
Direction
Protocol(s)
Ports
Purpose
Service
Message Queuing
{TCP,UDP}
{Inbound,Outbound}
<EDM_Installation_Path>\EdmS
ervice.exe
EDM
Inbound /
Outbound
ANY
(MSMQ)
ANY
Main communication channel
Service
SIPLACE EDM Service
API (Soap In)
<EDM_Installation_Path>\EdmS
ervice.exe
EDM
Inbound
TCP
9001
Remoting end point
(.Net Remoting)
Service
SIPLACE EDM Service
Config API (Soap In)
<EDM_Installation_Path>\EdmS
ervice.exe
EDM
Inbound
TCP (http)
9003
Configuration service end
point
N/A
<EDM_Installation_Path>\EdmS
ervice.exe
Outbound
TCP (http)
ANY
Dynamic WCF endpoints
<EDM_Installation_Path>\EdmC
learingPool.exe,
EdmConfiguration.exe,
EdmLineServerDataTransferMa
nager.exe, EdmPSC.exe,
EdmService.exe, EdmTool.exe
Outbound
TCP (http)
ANY
Response to Inbound-
connections to port 9003
Application
SIPLACE EDM Tool
(Soap In)
<EDM_Installation_Path>\EdmT
ool.exe
Inbound
TCP
9002
EDM Tool command
Endpoint (.Net Remoting)
