Support Media 2.0 12/2014 Edition
12
Table of packages in Support Media versions
X = contained in Support Media
- = possibly required but removed due to redistribution restrictions or space reduction
* = removed but downloaded automatically if required
Release
R60/R65
R70
Support Media (DVD1)
1.15 & 1.16
2.0
.Net Framework 3.5 SP 1
X
X
.Net Framework 4.0
X
X
Adobe Reader 10.1
X
X
Apache Tomcat 5.5.36
X
X
Apache Tomcat 5.5.9
X
X
Apache Tomcat 7.0.55
X
AppSight BlackBox 7.6
X
X
Crystal Reports Basic 10.5.2.0
X
-
Crystal Reports Basic 13.0.1.220
X
X
Deepburner 1.9.0.228
X
X
FileZilla 2.2.30a (FTP)
X
X
Microsoft MSMQ Hotfix 2554746
X
X
Microsoft Web Service Enhancements 3.0
X
X
Microsoft XML Parser 6.0
X
X
PowerShell V1 for XP/W2003/Vista
*
-
PowerShell V2 for Vista/W2008
*
-
Root Certificates Update December 2012
X
X
SQL 2005 SP 4 Express Update
X
-
SQL 2008 R2 SP 2 Express Update
X
X
SQL 2008 R2 SP 2 Express with Tools
X
X
SQL 2008 R2 SP 2 Server Update
*
*
SQL 2008 SP 3 Express Update
X
-
Support Media 2.0 12/2014 Edition
13
Release
R60/R65
R70
Support Media (DVD1)
1.15 & 1.16
2.0
SQL 2012 Express with Tools
*
*
SQL 2012 SP 1 + CU 2 Express with Tools
2
-
-
SQL 2012 SP 1 CU 2 Express Update
2
-
-
SQL 2012 SP 1 CU 2 Server Update
2
-
-
SQL 2012 SP 1 Express Update
*
*
SQL 2012 SP 1 Server Update
*
*
SQL 2012 SP 2 KB2958429
-
*
SQL 2012 SP 2 CU 2 KB2983175
-
*
SQL Backward Compatibility Components 8.05.2309
X
X
SQL XML 4.0 SP 1
X
X
Sun JRE 1.6.0.01
X
-
Sun JRE 1.6.0.04
X
X
Sun JRE 1.6.0.43
X
X
Sun JRE 7.0.670.1
X
Visual C++ 2005 SP 1 KB973544
X
X
Visual C++ 2010 SP 1 Redistributable
X
X
Visual C++ 2012 Update 4 Redistributable
X
X
Visual C++ 2013 Update 2 Redistributable
X
WinCDEmu 3.6
X
X
Windows Imaging Component
*
*
Windows Installer 3.1 (XP/W2003)
X
-
Windows Installer 4.5 (XP/W2003)
X
-
2
SQL 2012 SP 1 has a critical bug (KB2793634) which requires us to install Cumulative Update 2
(CU2).
Support Media 2.0 12/2014 Edition
14
4.4 Download of required, but not distributed software
The Support Media Prerequisite Analyzer offers multiple ways of downloading and
installing software components.
CAUTION
Legal changes regarding redistribution
The redistribution right is affecting the delivery through digital media like DVD as
well as manual delivery through ASM Assembly Systems personnel.
The following chapter describes the available options exemplarily.
4.4.1 Download options of Prerequisite Analyzer
In Prerequisite Analyzer on the Pending Actions Summary page, before installation of
prerequisites takes place, the media will be checked for the availability of all required
software packages. If at least one of the required packages is missing, you will get one of
the following two dialogs, with the options sorted by relevance. In this chapter, we give
you a basic overview of the options available.
Figure 4-1: Unavailable Installation Packages – No Additional Software Search Folder defined
► Click the Specify Search Folder button to select a (local) folder to search for missing
software packages.
► Click the button Download and install manually to show the list of missing software
packages together with information and links for manual download and installation.
► Click the button Download offline if you don’t have web- access from your computer
and want to download the missing packages using another computer with web-access.
NOTICE
Only local drives supported
