15
5.1.2.5 Blank run tape
PET tape specified by JUKI (product No.E3939802000)
Total tape length: 50 m
5.1.2.6 Tape feed amount
10mm to 12mm per feed
5.2 Options
5.2.1 Auto PWB Width Alignment
The PWB width is automatically changed to the input PWB width by stepping motor.
5.2.2 External Air Vent Unit
The external air vent unit is manually operated to fill the needle with glue (for air vent) when the
needle is mounted in the syringe containing glue at setting outside the system.
5.2.3 EPU
EPU is an abbreviation of External Programming Unit, which is software to create a program on
the PC.
5.2.4 UPS
UPS is an abbreviation of Uninterruptible Power Supply (Protection against blackout).
The following operation is performed by UPS.
The production control information is backed up and the production continuation information is
protected. After the program in the process of creation is saved, shutdown processing is
performed.
After a power recover, the production can be continued and the program in the process of
reaction can be recovered, and then the production control information can be continued.
5.2.5 BMR
A bad mark is given to a circuit on a multi-circuit PWB to prevent any component from being
placed on the circuit. The minimum diameter of a bad mark is 2.5 mm or more and the color of a
mark should be highly contrasted with the color of a board. The brightness can be switched when
the color of a board is bright (looks white).When you use an optional bad mark reader, the time for
recognizing one bad mark can be shortened by approximately 0.1 seconds with comparing with
the time taken with the standard OCC.
5.2.6 Leak Breaker
When the current flows besides the electric circuit, electricity is automatically intercepted.
5.2.7 LCD touch panel
It is an input device that operates the equipment touching as for the screen.
5.2.8 IS (Intelligent Shopfloor Solutions) : Production support system
This software is to be used with the JUKI mounters and dispensers, allow you to manage the
productions not only per line but also per floor. The IS manages and optimizes the
information and jobs for a whole manufacturing floor comprehensively to provide you
improved productivity, better manufacturing quality, and cost reduction.
*For the details of the IS, please refer to “IS Product specifications”.
16
5.2.9 JaNets : Production support system
As with our software IS, This software consolidates and optimizes information on JUKI
mounters allocated on the several lines (production site) to improve productivity and
production quality and to reduce production cost of each line.
Applicable models : RS-1, RX-7, RX-6 series, KE-3000 series, FX-3 series,
KE-2070/80 series, KE-2050/60 series, KD-2077
* For line configuration that the RS-1 is located, JaNets is required.
17
6 Control System
6.1 Storage method
The production program can be stored in a SSD or floppy disk.
The production control information can be stored in SSD.
* The SSD is a drive unit (solid state drive) using a flash memory as a storage medium on
behalf of HDD.
6.2 Production program capacity
Maximum number of steps per circuit: 3,000 steps
Maximum number of circuits per PWB: Number of matrix circuits 1200 and Number of
non-matrix circuits 200
Maximum number of steps per PWB: 10,000 steps
Maximum number of component data: 240
Maximum number of dispensing data: 240
Maximum number of registered marks: 1 set of BOC marks (2 or 3 pieces)
6.3 Pointing device
Mouse
Touch panel (option)
6.4 Input/output data format
The input/output of text format (XML format) is supported.
