4 Specifications

4.1 Equipment Specifications

4.1.1 Power supply specifications

Voltage: Three-phase 200 /220 /240 /380 /400/415 [V] AC specifications.

The voltage is selected depending on the destination at delivery from the factory.

Frequency: 50/60 Hz

Peak current (200 V AC): 22 A

* The primary side power cable is not attached.

** An appropriate cross-sectional area of the primary power cable may vary depending on the

cable routing conditions, length, and/or power voltage. Always use an appropriate cable

meeting the standards for the installation place from those stated in the Table below.

Power supply

Primary power cable

Less than 20m Less than 30m 40Less than 40m

200V/220V/240V AC 5.5 mm

or more 8.0 mm

or more 10.0 mm

or more

380V/400V/415V AC 5.5 mm

or more 5.5 mm

or more 6.0 mm

or more

4.1.2 Rated apparent power

1.1 kVA

Average power consumption at installation of each option.

4.1.3 Air pressure

0.5 ± 0.05 MPa

Dry air (oil, dust and other foreign substances shall be removed in advance. Water shall be

10ºC or less at dew point at a high pressure.)

The source pressure sensor is provided with an air-down detecting function and displays an

air-down alarm when the pressure goes down below 0.4 MPa.

4.1.4 Maximum air consumption

100 L/min (ANR)

4.1.5 Operating environmental conditions

Dispensing accuracy assurance temperature: +20ºC to +25ºC

Temperature: Ambient temperature + 10ºC to +35ºC

Humidity: 30% to 80% RH (Without condensation）

Altitude: 1,000m or less

4.1.6 Transport and storage environmental conditions

Temperature: -15ºC to +70ºC

Humidity: 20% to 95% RH (Without condensation)

4.1.7 External Dimensions

Except maximum projection (mm)

Dimensions

A (conveyor length)

1500

I (main body length)

1300

C (excluding LCD)

1393

H (left-side conveyor rail protection)

125

Dimensions

Conveyor height

900mm

Conveyor height

950mm

B(from the floor the top surface of conveyor belt)

900

950

D(from the floor to the bottom of keyboard)

1005

1055

E(from the floor to the surface of vision monitor)

1440

1490

F(from the floor to the top surface of vision monitor)

1710

1760

G(from the floor to the surface of signal light)

2000

2050

4.1.8 Mass of the main body

Approx. 1,400 kg

4.1.9 Noise

80 dB (A) or less Conforming to JIS Z 8731.

4.2 Dispensing Head Unit

4.2.1 Dispensing time

36,000 shots/hour

However, the above is the number of dispensing shots per hour at dispensing operation in the

following conditions.

・ Glue: Henkel Japan Ltd. Loctite 3609, Heraeus K.K. PD955M, or SOMAR

Corporation IR-120H

・ Continuous dispensing operation of the same dispense head (one of L, C, and R)

・ Moving distance: 5 mm (longer moving distance of X or Y) Dispensing angle: 0º

・ Needle: S needle

・ Dispensing diameter: φ0.6 mm

・ The PWB transport time, mark recognition time and blank run time are not included.

・ Applicable PWB: Glass epoxy board with t1.6 or more.

4.2.2 Dispensing accuracy (X,Y or θ)

4.2.2.1 Dispensing position (XY)

Needle name

Accuracy (±3 σ)mm

± 0.15

± 0.30

S-WST

± 0.15

・ Glue: Henkel Japan Ltd. Loctite 3609, Heraeus K.K. PD955M, or SOMAR Corporation IR-120H

・ The accuracy used for 3-dot PWB mark recognition on the L-board shall be used.

(A jig board without pattern/resist is used.)

4.2.2.2 Dispensing angle (θ)

±2°（±3σ）

・ This accuracy is for 2 needles.

4.2.2.3 Dispensing diameters

Needle name

Reference dispensing diameter (±3 σ)mm

0.6 ± 0.084

0.7 ± 0.07

1.1 ± 0.11

1.4 ± 0.14

1.2 ± 0.12

S-WST

0.6 ± 0.084
