20
8 Safety Specifications
8.1 Standard Specifications
8.1.1 Emergency stop
An emergency stop is performed by emergency stop button. When the emergency stop switch is
pressed, each axis is stopped immediately and the driving power supply of the servo motor is shut
off.
8.1.2 Safety cover
A cover is provided on the front side of the machine. The open/close status is detected by cover
open switch. When the cover is opened, the continuous operation is temporarily stopped. With the
safety cover open, the machine cannot be operated.
8.2 CE mark Specification
The CE mark specification is not available.
9 Maintenance Specifications
9.1 Troubleshooting
The improved help function can find out an abnormal status caused by any factor and a
recovering method to return to the normal status.
9.2 MTBA Display Function
This function calculates and displays the mean time interval time (MTBA) from a short stop
occurring during production to the next short stop.
10 Reliability Specifications
10.1 Service Life of the System
Seven years. However, consumables and the following parts are excluded. (For details, please
ask to JUKI Sales dept. )
• Plastic rail
• Bear cables assembly
• Sensor
• Camera
• Solenoid valve
• Air cylinder
• Air filter element
• Gas spring
• CD-ROM
Calculation standard for service life
22 hours/day
300 days/year
22 x 300 x 7 = 46,200 hours/7 years
◆
Revision record
Rev. Date Revised locations Revision contents Remarks
00 Feb.2008 First edition
01 Jun.2009 P9,10
Changed the component
height 2.0mm→2.5mm
Revised
02 Oct.2009
Supported IS and
revised environment
requirements
Revised
03 May 2017 P1, P15, P16 Supported JaNets Revised
04 Jul 2017 P1, P15, P16
Supported JaNets
Revised
