Error ID Error Name, Description, Cause, and Remedy
431618 Tray Feeder Zeroing Error (Block1)
The other pallet was detected from pallet store position during pulling.
-----
431619 Tray Feeder Zeroing Error (Block1)
Traverse zeroing error
-----
43161a Tray Feeder Zeroing Error (Block1)
Pallet chuck CLOSE error
-----
43161b Tray Feeder Zeroing Error (Block1)
Rack shutter CLOSE error
-----
43161c Tray Feeder Zeroing Error (Block1)
Magazine(Down) Error in shifting Pallet existence detection position.
-----
43161d Tray Feeder Zeroing Error (Block1)
Magazine(Up) Error in shifting Pallet existence detection position.
-----
43161e Tray Feeder Zeroing Error (Block1)
Missing detect sensor is detected although a pallet is stroed.
Please conrm whether Pallet is stored in Up/down magazine. All pallets are stored
but missing pallet is detected. Please adjust the missing detect sensor[B15406].
431801 Tray Feeder Zeroing Error (Block1)
Tray power supply not turning on(power supply cut o from main machine)
-----
431802 Tray Feeder Zeroing Error (Block1)
The Safety Cover of the body is open.
Please close the safety cover of the body, and then press READY button, lock the
cover.
431803 Tray Feeder Zeroing Error (Block1)
Tray maintenance cover OPEN
-----
431804 Tray Feeder Zeroing Error (Block1)
Traverse axis main circuit was cut o
-----
431805 Tray Feeder Zeroing Error (Block1)
Safety circuit cut o
-----
431806 Tray Feeder Zeroing Error (Block1)
Elevator axis main circuit cut o
-----
431807 Tray Feeder Zeroing Error (Block1)
Tray Safety Cover(Upper) is open.
Please close Tray safety cover(Upper), and then press READY button, lock the
cover.
3.4 Tray Feeder (Block1)
4OM-1751
3-601701-005
Error ID Error Name, Description, Cause, and Remedy
431808 Tray Feeder Zeroing Error (Block1)
Tray Safety Cover(Center) is open.
Please close Tray safety cover(Center), and then press READY button, lock the
cover.
431809 Tray Feeder Zeroing Error (Block1)
Tray Safety Cover(Lower) is open.
Please close Tray safety cover(Lower), and then press READY button, lock the
cover.
43180a Tray Feeder Zeroing Error (Block1)
Feeder base is Ready On
Please conrm Feeder Cart set correctly, and press Feeder Base READY button.
43180b Tray Feeder Zeroing Error (Block1)
No Magazine(Upper)
Please set Magazine(Upper).
43180c Tray Feeder Zeroing Error (Block1)
No Magazine(Lower)
Please set Magazine(Lower).
43180e Tray Feeder Zeroing Error (Block1)
Traverse axis Servo Alarm
-----
431810 Tray Feeder Zeroing Error (Block1)
Elevator axis Servo Alarm
-----
431811 Tray Feeder Zeroing Error (Block1)
Miss-Pickup comp. Detection 8mm[B15417]
-----
431812 Tray Feeder Zeroing Error (Block1)
Miss-Pickup comp. Detection 14mm[B15418]
-----
431813 Tray Feeder Zeroing Error (Block1)
Miss-Pickup comp. Detection 28mm[B15419]
-----
431814 Tray Feeder Zeroing Error (Block1)
Pallet chuck is not shut
-----
431815 Tray Feeder Zeroing Error (Block1)
The pallet Miss-Set was detected.
-----
431816 Tray Feeder Zeroing Error (Block1)
Magazine(Lower) Rack Shutter on the operator side is open.
-----
431817 Tray Feeder Zeroing Error (Block1)
Magazine(Lower) Rack Shutter on the side of Traverse is open.
-----
3.4 Tray Feeder (Block1)
4OM-1751
3-611701-005
Error ID Error Name, Description, Cause, and Remedy
431818 Tray Feeder Zeroing Error (Block1)
Magazine(Lower) is not done positioning yet.
Please conrm the Magazine position and Magazine lock lever.
431819 Tray Feeder Zeroing Error (Block1)
Elevator axis safety relay
-----
43181a Tray Feeder Zeroing Error (Block1)
Magazine(Upper) Rack Shutter on the operator side is open.
-----
43181b Tray Feeder Zeroing Error (Block1)
Magazine(Upper) Rack Shutter on the Traverse side is open.
-----
43181c Tray Feeder Zeroing Error (Block1)
Magazine(Upper) is not done positioning yet.
Please conrm the Magazine position and Magazine lock lever.
43181d Tray Feeder Zeroing Error (Block1)
Pick-up miss cmpnt detect
-----
431820 Tray Feeder Zeroing Error (Block1)
Zeroing incomplete
-----
431821 Tray Feeder Zeroing Error (Block1)
An elevator cannot move to the upper direction.There is XY beam at the ascent of
elevator position.
Perform All zeroing
434001 Tray Feeder Zeroing Error (Block1)
Tray feeder sequence timeout
-----
434002 Tray Feeder Zeroing Error (Block1)
Tray feeder sequence error
-----
438302 Tray Feeder Zeroing Error (Block1)
Elevator unit was not detected.
Please set up Tray Unit in Exchange location.
438303 Tray Feeder Zeroing Error (Block1)
Connector of Feeder base is not positioned correctly
Please Operate it after connecting connector of Feeder Base.
438304 Tray Feeder Zeroing Error (Block1)
Connector of Tray is not positioned correctly
Operate it after connecting connector of Tray.
438305 Tray Feeder Zeroing Error (Block1)
Time-out of Clamp operating of Elevator Unit.
-----
3.4 Tray Feeder (Block1)
4OM-1751
3-621701-005
