4OM-1751 1-13 2.3 Monthly Maintenance Grease Symbols MP1 : DAPHNE GREASE MP No. 1 Object Unit Inspection, Cleaning, and Lubricating Spots Work Grease Required T ools Check 4.3 Component Recognition Camera Section T eachi…
4OM-1751
1-12
2.2 Weekly Maintenance
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.1 Air Source
Drain
Cleaning
----- -----
4.3 Component
Recognition
Camera Section
Fiducial Mark
Cleaning
----- Lens Cleaning Cloth
4.5 Feeder Cart
Section
Groove on Feeder Base
Cleaning
----- Vacuum Cleaner
4.6 Cutter Section
Cutter Box Inside
Cleaning
----- Vacuum Cleaner
Linear Guide
4.7 Head Section
High Speed
Section
Vacuum Nozzle
Cleaning
----- Lens Cleaning Cloth,
Air Gun, Rag
Nozzle Filter
Change
----- Filter Insertion Jig
(High-Speed Nozzle),
Filter Insertion Jig
(Nozzle for Middle-Size and
Odd-Shape Components),
Filter Removing Jig
4.9 PCB Positioning
Section
Upper Surface of Feeder
Base
Cleaning
----- Vacuum Cleaner
4.10 Conveyor Section
Support Pin Detection
Sensors
Cleaning
----- Rag
PCB Detection Sensor,
PCB Detection Sensor
Fiber,
PCB Detection Sensor
Mirror
Cleaning
----- Rag
T4A9
1304-001
2.2 Weekly Maintenance
4OM-1751
1-13
2.3 Monthly Maintenance
Grease Symbols
MP1
: DAPHNE GREASE MP No. 1
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.3 Component
Recognition
Camera Section
Teaching Plate
Cleaning
----- Rag
QFP Glass Plate Jig
Cleaning
----- Lens Cleaning Cloth
4.7 Head Section
High Speed Head
Cleaning
----- Lens Cleaning Cloth
4.11 Nozzle Stocker
Section
Nozzle Stocker for
High Speed Nozzle
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
4.11 Nozzle Stocker
Section
Nozzle Stocker
for Multi-Function
Nozzle
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
Carn Follower
Cleaning,
Lubrication
NM1
T4A10
1304-001
2.3 Monthly Maintenance
4OM-1751
1-14
2.4 Quarterly Maintenance
Grease Symbols
MP1
: DAPHNE GREASE MP No. 1
NM1
: MOLYNOC GREASE AP1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
4.1 Air Source
Filter
Cleaning
-----
4.2 Vacuum System
Driving Section
Filter
Cleaning
-----
4.4 Feeder Base
Worm Gear
Lubrication
NM1
4.6 Cutter Section
Linear Guide
Lubrication
MP1
Needle Bearing
Lubrication
MP1
4.7 Head Section
High Speed Head
Nozzle U/D Ball Screw
(NL Axis)
Cleaning,
Lubrication
MP1
Head U/D Ball Screw
(HL Axis)
Cleaning,
Lubrication
MP1
Head U/D Linear Guide
(HL Axis)
Cleaning,
Lubrication
MP1
Center Spline
Lubrication
MP1
Carn Follower
Cleaning,
Lubrication
MP1
Nozzle Change Carn
Face (Upper Side)
Cleaning,
Lubrication
MP1
Vacuum Filter
Replacement
-----
Vacuum Nozzle
Inspection
-----
4.7 Head Section
Multi-Functional
Head
Ball Screw (2 locations)
Lubrication
MP1
Linear Guide
(2 locations)
Lubrication
MP1
Vacuum Filter
Change
----- Filter Attachment /
Detachment Jig
Vacuum Nozzle
Inspection
-----
4.8 X/Y Beam Section
Cleaning,
Lubrication
MP1
* Y-Axis Linear Guide
Cleaning,
Lubrication
MP1
Cleaning
-----
Y-Axis Linear Scale
Cleaning
-----
Cleaning,
Lubrication
DE3
4.9 PCB Positioning
Section
* Ball Screw
Cleaning,
Lubrication
MP1
4.10 Conveyor Section
* Linear Guide
Cleaning,
Lubrication
MP1
T4A11
1304-001
2.4 Quarterly Maintenance
