Error ID Error Name, Description, Cause, and Remedy
438509 Tray Feeder Zeroing Error (Block1)
Communication Status Error(Out of Connection number)
Please conrm AE-LINK wiring and Power wiring.
43850A Tray Feeder Zeroing Error (Block1)
Communication Status Error(SV-VET Error)
Please conrm AE-LINK wiring and Power wiring.
43850B Tray Feeder Zeroing Error (Block1)
Failed to read the number of Axes
Please conrm AE-LINK wiring and Power wiring.
43850C Tray Feeder Zeroing Error (Block1)
Driver-axis is not connected.
Please conrm AE-LINK wiring and Power wiring.
43850D Tray Feeder Zeroing Error (Block1)
Elevator1-axis is not connected.
Please conrm AE-LINK wiring and Power wiring.
43850E Tray Feeder Zeroing Error (Block1)
Elevator2-aixs in not connected.
Please conrm AE-LINK wiring and Power wiring.
438510 Tray Feeder Zeroing Error (Block1)
Motor Breaker Trip Error
-----
438511 Tray Feeder Zeroing Error (Block1)
Elevator Unit is not connected.
Please connect Elevator unit in Unit exchange menu.
438512 Tray Feeder Zeroing Error (Block1)
All connectors of Elevator Unit are not connected.
Please conrm the connection to all connector of Elevator Unit
438513 Tray Feeder Zeroing Error (Block1)
Failed to start-up Communication of SV-NET.
Please conrm AE-LINK wiring and Power wiring.
438514 Tray Feeder Zeroing Error (Block1)
Failed to turn on Tray.(Time-out)
-----
438515 Tray Feeder Zeroing Error (Block1)
(At nishing Auto Run) Tray operation(Block1) is not completed within a specied
time.
Please push Emergency Stop button.
438516 Tray Feeder Zeroing Error (Block1)
To discriminate the connected tray cart is failed.
Please press READY switch on Feeder Base again. Please contact to the service
when to output the error is continuous.
438517 Tray Feeder Zeroing Error (Block1)
Timeout in discriminating the tray cart.
Please press READY switch on Feeder Base again. Please contact to the service
when to output the error is continuous.
3.4 Tray Feeder (Block1)
4OM-1751
3-641701-005
Error ID Error Name, Description, Cause, and Remedy
438601 Tray (Servo Error) (Block1)
Error of Power Driver, Over-current
Please conrm Motor wiring, Exchange Motor and Driver.
438602 Tray (Servo Error) (Block1)
Overload Alarm
Please conrm Motor wiring, Exchange Motor and Driver.
438603 Tray (Servo Error) (Block1)
Speed Alarm
You need to re-adjust Motor Gain.
438604 Tray (Servo Error) (Block1)
Multi-rotation Error
Please conrm Motor wiring, Exchange Motor and Driver.
438605 Tray (Servo Error) (Block1)
The value of Deviation Counter was over the set value
Please conrm the wiring of Origin Sensor, or exchange Driver.
438606 Tray (Servo Error) (Block1)
Power Drive detected temperature error.
Ambient Temperature is too high. Or, exchange driver.
438607 Tray (Servo Error) (Block1)
Sensor Error
Please conrm Motor Encoder wiring. Or, exchange motor
438608 Tray (Servo Error) (Block1)
High Drive voltage
Insucient power capacity. Please exchange driver.
438609 Tray (Servo Error) (Block1)
Low drive voltage
Please conrm the operating Power wiring which is inserted to driver.
43860A Tray (Servo Error) (Block1)
Reading Error on permanent memory
Please exchange driver.
43860B Tray (Servo Error) (Block1)
Reading Error on permanent memory
Please exchange driver.
43860C Tray (Servo Error) (Block1)
CPU Error
Please exchange driver.
43860D Tray (Servo Error) (Block1)
Parameter Error
Please conrm the changed parameter.
43860E Tray (Servo Error) (Block1)
Alarm code readout failed
-----
438701 Elevator Recede position operating error (Block1)
Elevator pre-check error
-----
3.4 Tray Feeder (Block1)
4OM-1751
3-651701-005
Error ID Error Name, Description, Cause, and Remedy
438702 Elevator Recede position operating error (Block1)
Error of calculating Elevator movement position
-----
438703 Elevator Recede position operating error (Block1)
Elevator Start Time-out
-----
438704 Elevator Recede position operating error (Block1)
Elevator movement error
-----
438705 Elevator Recede position operating error (Block1)
Elevator movement Time-out
-----
438801 Elevator comp. position operating error (Block1)
Elevator pre-check error
-----
438802 Elevator comp. position operating error (Block1)
Error of calculating Elevator movement position
-----
438803 Elevator comp. position operating error (Block1)
Elevator Start Time-out
-----
438804 Elevator comp. position operating error (Block1)
Elevator movement error
-----
438805 Elevator comp. position operating error (Block1)
Elevator movement Time-out
Please conrm the operating Power wiring which is inserted to driver.
