Error ID Error Name, Description, Cause, and Remedy 51 1220 Transfer Section's Preparation Error Upward movement on PCB Stopper(REV) is abnormal. There is a possibility that PCB stopper is broken or not Air in. 51 1…
Error ID Error Name, Description, Cause, and Remedy
511207 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AL) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511208 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511209 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511210 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AR) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511211 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511212 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511213 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BL) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511214 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511215 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BL) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511216 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BR) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511217 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511218 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BR) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511219 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(REV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
3.12 Automatic Operation Error
4OM-1751
3-1331701-005
Error ID Error Name, Description, Cause, and Remedy
511220 Transfer Section's Preparation Error
Upward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511221 Transfer Section's Preparation Error
Downward movement on PCB Stopper(REV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511222 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(AREV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511223 Transfer Section's Preparation Error
Upward movement on PCB Stopper(AREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511224 Transfer Section's Preparation Error
Downward movement on PCB Stopper(AREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511225 Transfer Section's Preparation Error
Upward Limit and Downward Limit on PCB Stopper(BREV) are detected
simultaneously.
Please check out the wiring and adjust Limits.
511226 Transfer Section's Preparation Error
Upward movement on PCB Stopper(BREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511227 Transfer Section's Preparation Error
Downward movement on PCB Stopper(BREV) is abnormal.
There is a possibility that PCB stopper is broken or not Air in.
511301 Added squeeze error
Added squeeze is not completed.
Open the safety cover and check the placed components. Then, please remove
or revise them.
511401 Automatic correction of missed standard mark
Error in automatic correction of missed standard mark.
Please redo oset teaching of PCB mark position.
511402 Automatic correction of missed standard mark
Timeout of automatic correction of missed standard mark.
Please redo oset teaching of PCB mark position.
511403 Automatic correction of missed standard mark
Error in recognizing standard mark.
Please redo oset teaching of PCB mark position.
T4C14
3.12 Automatic Operation Error
4OM-1751
3-1341701-005
3.13 Auto Teaching
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
600101 P.C.B. recog camera & beam oset teach.
-----
-----
600102 P.C.B. recog camera & beam oset teach.
Error of Recognition Command response.
-----
600103 P.C.B. recog camera & beam oset teach.
Error of coordinates calculation.
-----
600104 P.C.B. recog camera & beam oset teach.
Error of Data set for XY Beam.
-----
600105 P.C.B. recog camera & beam oset teach.
Error of moving for XY Beam.
-----
600106 P.C.B. recog camera & beam oset teach.
Time-out in XY Beam
-----
600107 P.C.B. recog camera & beam oset teach.
Time-out of communication with recognition.
-----
600108 P.C.B. recog camera & beam oset teach.
Recognition failure of checker mark on parts recognition camera.
-----
600109 P.C.B. recog camera & beam oset teach.
Recognition failure of checker on reference pin.
-----
60010a P.C.B. recog camera & beam oset teach.
Recognition failure of checker mark on glass jig.
-----
600201 Comp. Recog. Camera oset teach.
Could not recognize the glass Jig.
Please conrm that Glass Jig is set on Glass Jig place.(Check it because there is
a possibility that nozzle is not on head, or vacuum is not "ON".)
600202 Comp. Recog. Camera oset teach.
The result of Teaching is out of permission values.
Please conrm whether Glass Jig is picked-up correctly or not. Please adjust it
with Teach Plate Oset if not.
600203 Comp. Recog. Camera oset teach.
Error of Recognition command response.
-----
600204 Comp. Recog. Camera oset teach.
Error of coordinates calculation.
-----
4OM-1751
3-1351701-005
