OM-1670
14
Specied lubrication tools
(1) Brush
Use a brush whose bristles do not come off if possible.
Notice
Do not use a brush for ball screws and splines.
(2) Vinyl Gloves
Use a pair of vinyl gloves to apply grease or oil by hand.
(3) Syringe
Maker : TERUMO
This gun can be used for two types of greases.
Use the syringes and the nozzle properly.
Two Types of Greases
: DAPHNE EPONEX GREASE No. 1
MOLYNOC GREASE AP1
Appearance
Fig. 8
Table 3
Standard Shape Part No. Remarks
Syringe
228A0171
Marker : TERUMO
10ml SS-10-LZ
Nozzle No.19
(Color : Brown)
0916D108
Maker : NIPRO
Inside Diameter :
f
0.79
Length : 65 mm Flat End
1011-001
8.2 Preparation for Maintenance
OM-1670
15
8.3 Maintenance Cheak List
8.3.1 Monthly Maintenance
Grease Symbols
NM1
: MOLYNOC GREASE AP1
Table 4
Maintenance Spots
Task Grease Required Items Check
Name Ref.
Nozzle Stocker for
Multi-Functional
Nozzle
Nozzle Storage
Section
Fig.10 Cleaning ----- Vacuum Cleaner
Cam Follower Fig.11
Cleaning,
Lubrication
NM1 Oiled Reg
8.3.2 Quarterly Maintenance
Grease Symbols
DE1
: DAPHNE EPONEX GREASE No.1
NM1
: MOLYNOC GREASE AP1
Table 5
Maintenance Spots
Task Grease Required Items Check
Name Ref.
Nozzle Stocker for
Multi-Functional
Nozzle
Nozzle Stocker
Sliding Area
Fig.10
Cleaning,
Lubrication
DE1
Vacuum Cleaner,
Oiled Reg
Shutter Flange Pin
Sliding Section
Fig.11
Cleaning,
Lubrication
NM1 Oiled Reg
1011-001
8.3 Maintenance Cheak List
OM-1670
16
8.4 Maintenance Method
8.4.1 Understanding of Maintenance Items on Each Section
Claried in this session are the spots of the nozzle stocker for multi-functional
nozzle to be maintained periodically.
View of Inspection, Cleaning, Lubrication, and Adjustment Spots
Nozzle Storage Section
Every Month Cleaning
Suck dirt and dust with a vacuum cleaner.
[1]
[2]
[3]
Fig. 9
[1]
Maintenance Spot
[2]
Cycle and Contents of Maintenance
[3]
Details of Maintenance
