OM-1670
19
9. Troubleshooting
9.1 Starting Guidance
Reference
Refer to "Troubleshooting" in "Chapter 2" of the instruction manual (Vol. 4) for
the main machine for details.
9.2 Error IDs and Remedial Procedures
Reference
Refer to "Troubleshooting based Error ID" in "Chapter 3" of the instruction
manual (Vol. 4) for the main machine for details.
1011-001
9. Troubleshooting
OM-1670
201011-001
10. Specications
Table 6
noitpircseDmetI
1. Model GS-NM100/101/102/103
2. Applicable
Model
SIGMA-G4/G5
3. Configuration Nozzle Stocker for Multi-Functional Nozzle (GS-NM100/101/102/103)
• This consists of the change section and the cylinder section as a set.
Change Section of the Nozzle Stocker for Multi-Functional Nozzle (G -S003-
09/GS-NM111/112/113)
• Shortening the pattern program change time without any nozzle offline
setup
• Prevention of nozzle missing
Cylinder Section of the Nozzle Stocker for Multi-Functional Nozzle (GS-
NM120)
• Change section of the nozzle stocker for multi-functional nozzle in
SIGMA-G4/G5, with which the nozzle stocker (G -S003-09/GS-
NM111/112/113) can be installed on the unit base.
4. Applicable
Nozzle
• FA, FC, FE, FF, FY, WC, WE, WF, WG, WH, WN, WS, WT, YA, YF, YX
Series
• FR Series
Note : The FR series has been designed specially for GS-NM101/102/103.
5. Number of
Stockable
Nozzles
GS-NM100 : Max. 9 nozzles
GS-NM101 : Max. 7 nozzles
GS-NM102 : Max. 5 nozzles
GS-NM103 : Max. 3 nozzles
10. Specications
OM-1670
21
10. Specications
Table 7
noitpircseDmetI
6. Nozzle Stocker
Installation
Pattern and
Conditions
The nozzle stocker arrangement pattern and installation conditions are
described as follows.
SIGMA-G5 Nozzle Stocker Arrangement Pattern
Nozzle Stocker 1
Not attachable
Attachable (Note a)
NST1-1
Not attachable
Attachable
NST1-2
NST1-3
NST1-4
Nozzle Stocker 2
Not attachable
Attachable
NST2-4
NST2-3
NST2-2
NST2-1
Not attachable
Attachable (Note a)
SIGMA-G4 Nozzle Stocker Arrangement Pattern
Nozzle Stocker 1
Not attachable
Attachable (Note a)
NST1-1
Not attachable
Attachable
NST1-2
NST1-3
NST1-4
Nozzle Stocker 2
Not attachable
Attachable (Note a)
NST2-1
NST2-2
NST2-3
NST2-4
Not attachable
Attachable
Notes: (a) When the nozzle stocker for multi-functional nozzle is added to
NST1-4 or NST2-4, the nozzle stocker adding HLS board (GS-
NL100) is required.
(b) When the FULL size multi-layer tray feeder (GS-FP200) is used,
only the slots of NST1-1 and NST2-1 on the attachment side can
be used and the addition of any high-speed nozzle stocker is not
available.
7. Number of
Installable
Nozzle Stockers
Max. 4 units (using the nozzle stocker adding HLS board)
8. Mass Change Section of the Nozzle Stocker for Multi-Functional Nozzle :
Approx. 1.25 kg
Cylinder Section of the Nozzle Stocker for Multi-Functional Nozzle :
Approx. 1.00 kg
9. Dimensions Approx. 300 (Width) mm × 105 (Depth) mm × 256 (Height) mm
