Error ID Item Description 701201 Tray 2 Pallet Returning Error No Pallet at Start of Returning Operation (BPH514) (Cause 1) Self-Diagnostics Error Message (Remedy 1) Check the condition of the pallet detection (BPH514). …
Error ID Item Description
700201 Tray 2 Precheck Error L1 Axis Zeroing not completed
700202 Tray 2 Precheck Error L2 Axis Zeroing not completed
700203 Tray 2 Precheck Error TV2 Axis Zeroing not completed
700204 Tray 2 Precheck Error EV2 Axis Zeroing not completed
700205 Tray 2 Precheck Error
700206 Tray 2 Precheck Error
700207 Tray 2 Precheck Error
700601 Tray 2 Interlock
700602 Tray 2 Interlock
700603 Tray 2 Interlock
700604 Tray 2 Interlock
700605 Tray 2 Interlock
701001 Tray 2 Supply Operation Error
701002 Tray 2 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
701003 Tray 2 Supply Operation Error Drawout Tray Step No. Mismatch (Returning)
701004 Tray 2 Supply Operation Error Illegal Operation Mode (System)
701005 Tray 2 Supply Operation Error Indefinite TV-Axis Position
701101 Tray 2 Pallet Returning Error Elevator Moving Position Error
701102 Tray 2 Pallet Returning Error Elevator Operation Error
701103 Tray 2 Pallet Returning Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-113-11 AHB01ETRP
Error ID Item Description
701201 Tray 2 Pallet Returning Error No Pallet at Start of Returning Operation (BPH514)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701202 Tray 2 Pallet Returning Error Prechecking Error
701203 Tray 2 Pallet Returning Error Traverse Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701204 Tray 2 Pallet Returning Error No Pallet at Start and End of Returning Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection.
701205 Tray 2 Pallet Returning Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Remove the pallet being drawn out.
701206 Tray 2 Pallet Returning Error
701301 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (Before
Operation)
701302 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (During
Operation)
701303 Tray 2 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-12 AHB01ETRP
0206-001 2-1 13-13 AHB01ETRP
Error ID Item Description
701401 Tray 2 Pallet Drawout Error No Pallet at Start of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701402 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
701403 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
701404 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
701405 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701406 Tray 2 Pallet Drawout Error No Pallet at End of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701407 Tray 2 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallets in the magazine. (Oblique Insertion, etc.).
701408 Tray 2 Pallet Drawout Error
701501 Tray 2 Elevator Change Positoin Change Position Movement Error (Before Operation)
Movement Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
