0206-001 2-1 13-13 AHB01ETRP Error ID Item Description 701401 Tray 2 Pallet Drawout Error No Pallet at Start of Drawout Operation (Cause 1) Self-Diagnostics Error Message (Remedy 1) Check the condition of the pallet dete…
Error ID Item Description
701201 Tray 2 Pallet Returning Error No Pallet at Start of Returning Operation (BPH514)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701202 Tray 2 Pallet Returning Error Prechecking Error
701203 Tray 2 Pallet Returning Error Traverse Operation Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701204 Tray 2 Pallet Returning Error No Pallet at Start and End of Returning Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection.
701205 Tray 2 Pallet Returning Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Remove the pallet being drawn out.
701206 Tray 2 Pallet Returning Error
701301 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (Before
Operation)
701302 Tray 2 Pallet Drawout Error Elevator Drawout Level Movement Error (During
Operation)
701303 Tray 2 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0206-001 2-1 13-12 AHB01ETRP
0206-001 2-1 13-13 AHB01ETRP
Error ID Item Description
701401 Tray 2 Pallet Drawout Error No Pallet at Start of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701402 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (Before
Operation)
701403 Tray 2 Pallet Drawout Error Traverse Chuck Position Movement Error (During
Operation)
701404 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (Before
Operation)
701405 Tray 2 Pallet Drawout Error Traverse Drawout Position Movement Error (During
Operation)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701406 Tray 2 Pallet Drawout Error No Pallet at End of Drawout Operation
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701407 Tray 2 Pallet Drawout Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallets in the magazine. (Oblique Insertion, etc.).
701408 Tray 2 Pallet Drawout Error
701501 Tray 2 Elevator Change Positoin Change Position Movement Error (Before Operation)
Movement Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
Error ID Item Description
701502 Tray 2 Elevator Change Positoin Change Position Movement Error (During Operation)
Movement Error
701503 Tray 2 Elevator Change Positoin
Movement Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
701601 Tray 2 Feeder Zeroing Error The rack shutter did not open within the specified
time. (0101)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensors BPS501 and BPS503.
701602 Tray 2 Feeder Zeroing Error The pallet chuck did not close within the specified
time. (0201)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check Sensor BPS512.
701603 Tray 2 Feeder Zeroing Error A pallet was detected with the pallet not being drawn
out. (0202)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the condition of the pallet detection (BPH514).
701604 Tray 2 Feeder Zeroing Error Failed in the setting of driving waves. (0203)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0206-001 2-1 13-14 AHB01ETRP
3.3 Error IDs and Remedial Procedures
