Error ID Item Description
01 39 3 20007 "Component Library View Range Set" Not -----
Supported!
01 39 3 22001 "Component Library Polarity detn" Not Supported! -----
01 39 3 22002 "Component Library Polarity Inspection method" -----
Not Supported!
01 39 3 22003 Error in "Component Library Polarity Detn -----
Inspection Pos X or Y" Data.
01 39 3 22004 Error in "Component Library Polarity Detn -----
Inspection range" Data.
01 39 3 23001 "Component Library Upper/Lower surface detn" -----
Not Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
01 39 3 24102 Error in "Component Library Mold size tolerance -----
X or Y" Data.
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 24201 "Component Library Outward Length detn" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
01 39 3 24202 Error in "Component Library Outward Length tol" -----
Data.
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 25101 "Component Library Lead width detn" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
4.3 Recognition Error IDs and Remedial Procedures
0206-003 2-137 AHB01ETRP
Error ID Item Description
01 39 3 25102 Error in "Component Library Lead width tol" Data. -----
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 25201 "Component Library Lead posn(Latl dir)detn" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
01 39 3 25202 Error in "Component Library Lead posn(Latl dir)tol" -----
Data.
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 25301 "Component Library Lead posn(Long dir)tol" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
01 39 3 25302 Error in "Component Library Lead posn (Long dir) -----
tol" Data.
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 26101 "Component Library Electd Pos detn" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
4.3 Recognition Error IDs and Remedial Procedures
0206-002 2-138 AHB01ETRP
Error ID Item Description
01 39 3 26102 Error in "Component Library Electd Pos tol" Data. -----
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 39 3 26201 "Component Library Electd Size detn" Not -----
Supported!
(Cause 1) The data is not supported.
(Remedy 1) Set the supported data.
01 39 3 26202 Error in "Component Library Electd Size tol" Data. -----
(Cause 1) Wrong parameters are set.
(Remedy 1) Set correct parameters.
01 50 1 00000 Cam No. is incorrect -----
01 50 1 00001 Nozzle ID is incorrect -----
01 50 1 00002 Angle is incorrect -----
01 51 1 00000 Cam No. is incorrect -----
01 51 1 00001 Mark No. is incorrect -----
01 51 1 00002 Angle is incorrect -----
01 51 1 00003 P.C.B. Recognition Process ID is incorrect -----
01 51 1 00004 Recognition Method is incorrect -----
01 52 1 00000 Cam No. is incorrect -----
01 52 1 00001 Fdr.No. is incorrect -----
01 52 1 00002 Nozzle ID is incorrect -----
4.3 Recognition Error IDs and Remedial Procedures
0308-004 2-139 AHB01ETRP
