1 VERIFICATION AND TRACEABILITY 1.2 ENABLE VERIFICATION STANDALONE MANUAL VERIFICATION AND TRACEABILITY TQ SERIES 07/2020 11 1.2.3 Enable Item Verification 1. Select the Menu icon. 2. Select Programming . 3. The current …
1 VERIFICATION AND TRACEABILITY
1.2 ENABLE VERIFICATION
10 STANDALONE MANUAL VERIFICATION AND TRACEABILITY TQ SERIES 07/2020
6. Select Board Interlocking to display the following page:
Board interlocking determines what happens to the board when it fails verification. The Board
Interlock Position parameter determines where the board is held if Barcode Verification Action
is set to Hold.
7. Select the Input Interlock Position parameter.
8. Select Upline or Inroad depending on where the board is to be held after failing verification, if
the Barcode Verification Action parameter is set to Hold.
9. Select Accept.
10. Select Board Barcode Side.
11. Select Top or Bottom depending on which side of the board the barcode is located.
12. Select Accept.
13. Select Board Barcode Verification.
14. Select Enabled.
15. Select Accept.
16. Select Save And Exit.
17. Select Save And Exit.
18. Select Exit.
1 VERIFICATION AND TRACEABILITY
1.2 ENABLE VERIFICATION
STANDALONE MANUAL VERIFICATION AND TRACEABILITY TQ SERIES 07/2020 11
1.2.3 Enable Item Verification
1. Select the Menu icon.
2. Select Programming.
3. The current loaded program is highlighted.
4. Select Edit.
5. Select Top Side or Bottom Side.
6. Select Edit.
7. Select Item Verification to display the following page:
The status column shows a green tick of items that are enabled and blank when disabled.
Edit Rule Sets
Edit Rule Sets
Edit Rule Sets
Edit Rule Sets
8. Select at the right hand side of the item, in the Status column, to change the status.
9. Select Save And Exit.
10. Select Save And Exit.
11. Select Exit.
1 VERIFICATION AND TRACEABILITY
1.3 VERIFICATION ITEMS
12 STANDALONE MANUAL VERIFICATION AND TRACEABILITY TQ SERIES 07/2020
1.3 VERIFICATION ITEMS
The following is a default list of items that may be used for verification:
●
Board Clamp Front
●
Board Clamp Rear
●
Cleaner Fabric
●
Cleaner Solvent
●
Dedicated Tooling
●
Material
●
Operator Name
●
Print Medium
●
Print Medium Cartridge/Jar
●
Stencil
●
Spatula
●
Squeegee Blade Front
●
Squeegee Blade Rear
●
Squeegee Holder Front
●
Squeegee Holder Rear
●
Work Order
The permitted rules for the verification items may be a barcode, a serial number or a name. Care
must be taken when entering rules as these must be entered exactly when verification is reques-
ted.
Each verifiable item may have multiple rules associated with it allowing, for example, stencils from
two different manufacturers to be used on the same product run.
1.3.1 Create Item
A default list of items was included when the software was installed on the printer, items can be
created, edited or deleted. This section details creating a new item:
1. Select the Menu icon.
2. Select Programming.
3. Select Verification Item Definitions.
