G-45 01850406 01840406 Fixing accessories Article number Designation 01840406 Angular swiv el holder, shaft = Ø 8 x 25 mm, clamping Ø 8 mm 01850406 Angle holder with cylindrical shank, Ø 3/8 in, shaft = Ø 3/8 x 3.5 in Sq…
G-44
01840408
Article
number
Designation
01840408 Mounting rod with dovetail clamp, swivelling, shaft = Ø 4 x 64,35 mm
01840409 Mounting rod with dovetail clamp, swivelling, shaft = Ø 8 x 64,35 mm
Fixing accessories
Swivelling fixing rods with dovetail attachment
01840405
01850404
0184040701840404
Article
number
Designation
01840404 Swivel holder with dovetail grip, shaft = Ø 8 x 25 mm
01850404 Swivel holder with dovetail grip, shaft = Ø 3/8 x 1 in
01840405 Swivel holder with dovetail grip, shaft = Ø 8 x 90 mm
01850405 Swivel holder with dovetail grip, shaft = Ø 3/8 x 3-5/8 in
01840407 Swivel holder with dovetail grip, fine adjustment device, shaft = Ø 8 x 125 mm
074106026 Swivel holder with dovetail grip, Ø 4 and Ø 7 mm, shaft = Ø 8 x 133 mm
074106931 Swivel holder with dovetail grip, Ø 4 and Ø 7 mm, shaft = Ø 3/8 x 5-1/4 in
074106331 Swivel holder with dovetail grip, Ø 4 and Ø 5,5 mm, bar = 6 x 12,6 x 76 mm
Swivel holders
G-45
0185040601840406
Fixing accessories
Article
number
Designation
01840406 Angular swivel holder, shaft = Ø 8 x 25 mm, clamping Ø 8 mm
01850406 Angle holder with cylindrical shank, Ø 3/8 in, shaft = Ø 3/8 x 3.5 in
Squares holders
074111481
01850203
01840202
Article
number
Designation
01840202 Mounting rod, pin = Ø 5,6 mm, shaft = 8 x 80 mm
01850202 Fixing shank, pin Ø 7/32 in, shank = Ø 3/8 x 3.5 in
01850203 Fixing shank, pin Ø .22 in, bar = 1/4 x 1/2 x 3 in
074111481 Fixing shank, pin Ø 5/32 in, bar = 3/16 x 5/16 in
Fixing rod with pin
G-46
01860401
Article
number
Designation
01860401 Dovetail clamp with dovetail clamp, clamping = Ø 5,6 and Ø 9,5 mm
01860402 Dovetail clamp with dovetail clamp, clamping = Ø 7 and 9,5 mm
074108603 Dovetail clamp with dovetail clamp, clamping = Ø 7/32 and 5/32 in
Fixing accessories
Clamps
SPT
Article
number
Designation
SPT Swivel clamp, Ø 4,1 mm, axis = Ø 8 x 25 mm
Rotating holder
