G-46 01860401 Article number Designation 01860401 Dovetail clamp with do vetail clamp, clamping = Ø 5,6 and Ø 9,5 mm 01860402 Dov etail clamp with dovetail clamp, clamping = Ø 7 and 9,5 mm 074108603 Dovetail clamp with d…
G-45
0185040601840406
Fixing accessories
Article
number
Designation
01840406 Angular swivel holder, shaft = Ø 8 x 25 mm, clamping Ø 8 mm
01850406 Angle holder with cylindrical shank, Ø 3/8 in, shaft = Ø 3/8 x 3.5 in
Squares holders
074111481
01850203
01840202
Article
number
Designation
01840202 Mounting rod, pin = Ø 5,6 mm, shaft = 8 x 80 mm
01850202 Fixing shank, pin Ø 7/32 in, shank = Ø 3/8 x 3.5 in
01850203 Fixing shank, pin Ø .22 in, bar = 1/4 x 1/2 x 3 in
074111481 Fixing shank, pin Ø 5/32 in, bar = 3/16 x 5/16 in
Fixing rod with pin
G-46
01860401
Article
number
Designation
01860401 Dovetail clamp with dovetail clamp, clamping = Ø 5,6 and Ø 9,5 mm
01860402 Dovetail clamp with dovetail clamp, clamping = Ø 7 and 9,5 mm
074108603 Dovetail clamp with dovetail clamp, clamping = Ø 7/32 and 5/32 in
Fixing accessories
Clamps
SPT
Article
number
Designation
SPT Swivel clamp, Ø 4,1 mm, axis = Ø 8 x 25 mm
Rotating holder
G-47
01840501
Fixing accessories
Article
number
Designation
01840501 Centering holder, Ø 4 mm, shaft = Ø 4 x 25 mm
Centring holder
03238013
Article
number
Designation
03238013 Mounting lug
Mounting backs for lever-type test indicators
