LED Pair ing / Ins tallatio n Manua l 05/2014 Edit ion 31

LED Pairing / Installation Manual 05/2014 Edition

8.2 SIPLACE LED Pairing Controller Database – Board Grouping

Table

The Board Grouping table of the SIPLACE LED Pairing Controller database contains the following

entries:

Board Grouping table LED Pairing Controller

name

Data type Byte CI I P

Line Full Path

strLineFullPath

nvarchar(1024) 2048

Recipe Full Path

strRecipeFullPath

nvarchar(1024) 2048

Conveyor Lane

lConveyorLane

int 4

PCB individual barcode

strBarcode

nvarchar(1024) 2048 

Group Guid

strGroupGuid

nvarchar(36) 72 

Type of entry

IType

int 4

State of entry

IState

int 4

Timestamp when entry

was written

dtLastProcessed DateTime 8

Table 7-1: Board Grouping table

Type of entry:

0: Undefined

1: Independent board entry

2: Dependent board entry

State of entry:

0: Undefined

1: IndependentBoardLineEntered

2: IndependentBoardProduced

3: IndependentBoardCanceled

4: DependentBoardLineEntered

5: DependentBoardProduced

6: DependentBoardCanceled
