MRS T echnology f or 3D S P I The SE3000 SPI S ystem bri ngs the r evol ution ar y MRS techn ology to solder paste ins pec tion delivering hig her per formance in acc uracy and precision. Eective su ppres sion of m ulti…
Solder Paste Inspection (SPI)
Ultimate Precision Accuracy with World-Class Usability
SE3000™
|
3D SPI
• MRS Sensor for metrology grade accuracy at
production speed
• Dual mode sensor with high resolution and high speed
modes for maximum exibility
• SE3000™ X available for Large Board capability
SE3000™ DD
|
3D SPI
Dual Lane - Dual Sensor
• Dual MRS sensors delivers metrology grade
accuracy at production speed
• Flexibility to switch from dual to single lane
for large boards
• SE3000™ D Dual Lane option available
Multiple
MRS Sensor
Options
SQ3000™
+
|
Multi-Function
• Ultimate in Speed, Resolution and Accuracy for Advanced
Applications
• Multi-process capability for 3D AOI, SPI and CMM
• Delivering metrology grade accuracy at production speed,
powered by the new Ultra-High Resolution 5-Micron MRS
Sensor Technology
• Ideal for high-end applications for advanced SMT,
008004/0201 SPI, advanced packaging, and high-end
coordinate measurements
SQ3000™ | Multi-Function
• Ultimate in Speed and Accuracy
• Multi-process capability for 3D AOI, SPI and CMM
• Delivering metrology grade accuracy at
production speed, powered by MRS Technology
• SQ3000™ X available for Large Board capability
Multiple
MRS Sensor
Options
Multiple
MRS Sensor
Options
MRS Technology for 3D SPI
The SE3000 SPI System brings the revolutionary MRS technology to solder
paste inspection delivering higher performance in accuracy and precision.
Eective suppression of multiple reections is critical for highly accurate
measurements, making MRS an ideal technology solution for a wide range
of applications including those with very high quality requirements.
CyberOptics MRS Sensor architecture, extended from the award-winning
SQ3000 AOI platform, has been designed for use in solder paste inspection
applications. The unique sensor architecture with multi-view 3D sensors
and a parallel projector, simultaneously captures and transmits multiple
images in parallel while proprietary 3D fusing algorithms merge the images
together, delivering metrology grade accuracy at production speed.
SPI SYSTEMS
Solder Ball/ Blob Analysis, Solder Bridge, Insucient Solder, Tombstone
CyberOptics’ software delivers world-class user experience
with its intuitive interface that is extremely stable and simple to
use, enabling the shortest learning curve. With full multi-touch
experience, SPI software oers a range of features that enable
smarter and faster inspection:
• Seamless integration of all applications - Teach, Inspection,
Defect Review and Real-time SPC
• Unlimited undo-redo and global search options in Teach
• Loads of smart, informative and relevant charts that provide
yield summary, FPY information, hotspot display, top 10 pad
failures, historical panel and more.
• Easy, hassle-free operation using multi-touch, multi-selection,
pinch-zoom and pan-move options.
Closed Loop/ Feed-forward Ready
Reduce rework costs, increase production throughput and improve quality
CyberOptics’ SPI systems fully support feedback and feed forward capability with leading Solder Paste Printer and SMT
Mounter vendors. Closed loop feedback gives you the power to do more with SPI results – optimize printing process,
establish stencil cleaning cycles and ne-tune printer setup. While feed-forward capability improves the solderability of
smaller components by using the printing oset data for compensating parts placement. All this means reduced rework
costs, increased production throughput and improved quality.
Closed Loop Feedback Feed Forward Ready
Shifted solder
Corrected data of
shifted solder
Gives you the power to do more with SPI results - optimize
printing process, establish stencil cleaning cycles and ne-tune
printer set-up
Improves solderability of smaller components for
reduced rework cost, improved production throughput
and improved quality
All Major Screen
Printers
CyberOptics
CYBERREPORT
SPISOFTWARE
AOISOFTWARE
CYBERREPORT
CYBERCMM
SPISOFTWARE
AOISOFTWARE
CYBERCMM
CYBER
PRINTOPTIMIZER
CYBER
PRINTOPTIMIZER
Award-Winning SPI Software
Intuitive Design, Exceptional Usability
