MRS Technology for 3D SPI
The SE3000 SPI System brings the revolutionary MRS technology to solder
paste inspection delivering higher performance in accuracy and precision.
Eective suppression of multiple reections is critical for highly accurate
measurements, making MRS an ideal technology solution for a wide range
of applications including those with very high quality requirements.
CyberOptics MRS Sensor architecture, extended from the award-winning
SQ3000 AOI platform, has been designed for use in solder paste inspection
applications. The unique sensor architecture with multi-view 3D sensors
and a parallel projector, simultaneously captures and transmits multiple
images in parallel while proprietary 3D fusing algorithms merge the images
together, delivering metrology grade accuracy at production speed.
SPI SYSTEMS
Solder Ball/ Blob Analysis, Solder Bridge, Insucient Solder, Tombstone
CyberOptics’ software delivers world-class user experience
with its intuitive interface that is extremely stable and simple to
use, enabling the shortest learning curve. With full multi-touch
experience, SPI software oers a range of features that enable
smarter and faster inspection:
• Seamless integration of all applications - Teach, Inspection,
Defect Review and Real-time SPC
• Unlimited undo-redo and global search options in Teach
• Loads of smart, informative and relevant charts that provide
yield summary, FPY information, hotspot display, top 10 pad
failures, historical panel and more.
• Easy, hassle-free operation using multi-touch, multi-selection,
pinch-zoom and pan-move options.
Closed Loop/ Feed-forward Ready
Reduce rework costs, increase production throughput and improve quality
CyberOptics’ SPI systems fully support feedback and feed forward capability with leading Solder Paste Printer and SMT
Mounter vendors. Closed loop feedback gives you the power to do more with SPI results – optimize printing process,
establish stencil cleaning cycles and ne-tune printer setup. While feed-forward capability improves the solderability of
smaller components by using the printing oset data for compensating parts placement. All this means reduced rework
costs, increased production throughput and improved quality.
Closed Loop Feedback Feed Forward Ready
Shifted solder
Corrected data of
shifted solder
Gives you the power to do more with SPI results - optimize
printing process, establish stencil cleaning cycles and ne-tune
printer set-up
Improves solderability of smaller components for
reduced rework cost, improved production throughput
and improved quality
All Major Screen
Printers
CyberOptics
CYBERREPORT
SPISOFTWARE
AOISOFTWARE
CYBERREPORT
CYBERCMM
SPISOFTWARE
AOISOFTWARE
CYBERCMM
CYBER
PRINTOPTIMIZER
CYBER
PRINTOPTIMIZER
Award-Winning SPI Software
Intuitive Design, Exceptional Usability
CyberPrint OPTIMIZER™
Automatically optimizes the print process by proactively analyzing accurate trend data – rst-ever in the industry! Pre-dened
templates help you get started quickly while customizable rules support perfect customization for specic product needs.
With its predictive process improvement capability, you can get better yields and reduce downtime.
SPI SYSTEMS
CYBERREPORT
SPISOFTWARE
AOISOFTWARE
CYBERREPORT
CYBERCMM
SPISOFTWARE
AOISOFTWARE
CYBERCMM
CYBER
PRINTOPTIMIZER
CYBER
PRINTOPTIMIZER
Failure analysis drives line optimization and auto tolerance changes
Defect Correlation
SPI AOI AOI
FAIL
FAIL
FAIL
FAIL
FAIL FAIL
PASS PASS
PASS
CyberReport™ - Fast, Scaleable SPC Solution
CyberReport oers full-edged machine-level to factory-level SPC capability with powerful historical analysis and reporting
tools delivering complete traceability for process verication and yield improvement. CyberReport is easy to setup and
simple to use while providing fast charting with a compact database size.
Factory-level SPC
Line-level SPC
Machine-level SPC
Yield
CYBERREPORT
SPISOFTWARE
AOISOFTWARE
CYBERREPORT
CYBERCMM
SPISOFTWARE
AOISOFTWARE
CYBERCMM
CYBER
PRINTOPTIMIZER
CYBER
PRINTOPTIMIZER
Sample Report
