DeltaTherm IR Cure Module
Revision B / February 2020
Page 25 of 41
3. The Actual Temperature displays the current actual temperature of the heater
panel.
• On double-sided ovens, the upper and lower panels for each section are
controlled as one zone. The display temperature is the average temperature
(display temperature is filtered) of the upper and lower panel.
Note: With two-sided IR ovens, the upper panels may indicate temperatures higher
than the setpoint due to absorption of energy from the lower panels. This is normal.
4. The Max Deviation is the max allowable deviation from the target setpoint for the
specified zone and heater panel. Each enabled zone’s panels must reach and
maintain a temperature within the set deviations to run the product in Auto Cycle.
• Touch the Max Deviation box and a keypad will be shown.
• Enter the desired value.
• Press “ENT” to save the value and close the keyboard.
5. The Apply to All button will copy the setpoints and deviations of the Zone 1 upper
and lower panels to all over zones.
Note: Zone enable/disable options will not be copied over.
6. The name of the current Recipe will display. Any changes made to the recipe field
values will automatically be saved to the current recipe. Recipes are configured in
OEM mode.
DeltaTherm IR Cure Module
Revision B / February 2020
Page 26 of 41
Conveyor Speed
Figure 19: Conveyor Options
1. To change the conveyor speed while in Auto Cycle, select the Speed box. The
keypad will be shown.
• Enter the necessary value. The minimum speed is 0 feet per minute or 0
meters per minute, the maximum speed is 60 feet per minute or 19 meters
per minute.
• Press “ENT” to save the value and close the keypad.
• Select the arrow button to toggle the oven between left to right or right
to left conveyor direction.
DeltaTherm IR Cure Module
Revision B / February 2020
Page 27 of 41
Conveyor Width
This is an optional setting. Not all modules will have this option.
• Use the arrows on the screen or the “F1” and “ESC” button to scroll to the Setup-
Conveyor Adjust screen.
• Select the indicator to toggle this feature on and off.
• Place the board on the conveyor.
Figure 20: Conveyor Adjust
1. The screen displays the Target Recipe Width. If the width value is known, press the
value to manually enter the width setpoint. A keypad will be shown.
• Enter the necessary value. The metric unit range is from 50–500 mm (1.97-
19.69 in).
• Select “Save” to keep and use the new value.
2. If the width value is unknown, press the arrows to use the Auto Adjust Conveyor
Width. This will jog the conveyor in a negative or positive direction.
3. Once the target recipe width is correct, press the wrench icon to set the target
recipe width to the Current Conveyor Width.
Note: The clear board sequence will not run prior to jog.
Note: The conveyor width setpoint will not update during manual jog.
