DeltaTherm IR Cure Module
Revision B / February 2020
Page 31 of 41
Recovery from an Over-Temperature Error
1. Select “Silence Horn” to stop the alarm or “Clear Fault” to clear the fault.
2. Let the module temperature decrease.
3. Operate the module in manual mode or restart Auto Cycle. Look for the parameter
that causes the error.
4. If the error continues to repeat, refer to Section 12
.
Recovery from an Auto Conveyor Adjust Error
In the conveyor homing procedure, two errors may occur:
Error 1: The conveyor passes the home position sensor and hits the hard stop on one side.
1. When the conveyors pass the sensor and hit the hard stop, engage the “Emergency
Stop” button.
2. Open the left cabinet and find fuse number 70.
3. Release the fuse and disengage the “Emergency Stop” button. This will move the
conveyor toward the sensor.
4. When the conveyor passes the sensor, engage the “Emergency Stop” button again.
5. Examine the integrity and the wiring of the sensor.
6. Install fuse number 70, and home the conveyor again.
Error 2: The conveyor passes the software limit and hits the hard stop on the other side.
1. Engage the “Emergency Stop” button.
2. Open the left cabinet and find the conveyor direction relay (CR11).
3. Pull the blue button and disengage the “Emergency Stop” button. The conveyor
will move away from the hard stop.
4. Engage the “Emergency Stop” button again. This will stop the conveyor.
5. Push the blue button so it is in the original position in the relay.
6. Examine the wire and the conveyor position encoder.
DeltaTherm IR Cure Module
Revision B / February 2020
Page 32 of 41
Error Messages
The following are all the possible error messages generated by the PLC program.
Msg Number
DeltaTherm Fault Messages
100
Zone 1/2 Overtemp Monitor Fault
101
Zone 3/4 Overtemp Monitor Fault
102
Zone 5/6 Overtemp Monitor Fault
103
Zone 7/8 Overtemp Monitor Fault
104
Exhaust Fan Low Pressure.
105
Panel 1A Overtemp >285C
106
Panel 1B Overtemp >285C
107
Panel 2A Overtemp >285C
108
Panel 2B Overtemp >285C
109
Panel 3A Overtemp >285C
110
Panel 3B Overtemp >285C
111
Panel 4A Overtemp >285C
112
Panel 4B Overtemp >285C
113
Master Conveyor Width (CAN4) Drive Homing Timeout
114
Slave Conveyor Width (CAN6) Drive Homing Timeout
115
Data Table Error Values Not Downloaded
118
System Options Changed Reboot Required.
131
Control Power Timeout Fault
132
Autocycle Idle Timeout
141
Master Conveyor Transfer (CAN3) Communication Timeout
142
Master Conveyor Width (CAN4) Communication Timeout
143
Slave Conveyor Transfer (CAN5) Communication Timeout
145
Slave Conveyor Width (CAN6) Communication Timeout
147
Board Process Timeout Error
148
Panel 5A Overtemp >285C
149
Panel 5B Overtemp >285C
150
Panel 6A Overtemp >285C
DeltaTherm IR Cure Module
Revision B / February 2020
Page 33 of 41
151
Panel 6B Overtemp >285C
152
Panel 7A Overtemp >285C
153
Panel 7B Overtemp >285C
154
Panel 8A Overtemp >285C
155
Panel 8B Overtemp >285C
156
Zone 1A Intensity Fault Panel Never Reached Setpoint
157
Zone 1B Intensity Fault Panel Never Reached Setpoint
158
Zone 2A Intensity Fault Panel Never Reached Setpoint
159
Zone 2B Intensity Fault Panel Never Reached Setpoint
160
Zone 3A Intensity Fault Panel Never Reached Setpoint
161
Zone 3B Intensity Fault Panel Never Reached Setpoint
162
Zone 4A Intensity Fault Panel Never Reached Setpoint
163
Zone 4B Intensity Fault Panel Never Reached Setpoint
164
Zone 5A Intensity Fault Panel Never Reached Setpoint
165
Zone 5B Intensity Fault Panel Never Reached Setpoint
166
Zone 6A Intensity Fault Panel Never Reached Setpoint
167
Zone 6B Intensity Fault Panel Never Reached Setpoint
168
Zone 7A Intensity Fault Panel Never Reached Setpoint
169
Zone 7B Intensity Fault Panel Never Reached Setpoint
170
Zone 8A Intensity Fault Panel Never Reached Setpoint
171
Zone 8B Intensity Fault Panel Never Reached Setpoint
173
Zone 1A Deviation Fault
174
Zone 1B Deviation Fault
175
Zone 2A Deviation Fault
176
Zone 2B Deviation Fault
177
Zone 3A Deviation Fault
178
Zone 3B Deviation Fault
179
Zone 4A Deviation Fault
180
Zone 4B Deviation Fault
181
Zone 5A Deviation Fault
182
Zone 5B Deviation Fault
