28
06.2007
14
Technical Data
Switching system
Self-cleaning, double-break, snap action switching system (with
contact gap 2 x 0.5 mm).
1 normally closed or 1 normally open contact per element.
Snap-action switching elements with soldering terminals at the
sides: up to 4 switching element can be on a pushbutton (max. 4
normally closed and 4 normally open contacts).
Snap-action switching element with axial plug-in terminals 2.8 mm
stackable, only 1 switching element can be on a pushbutton.
Material
Material of contact
Gold plated silver
Switch housing
Plug-in-/soldering terminal
Diallylphthalate DAP, Polyamide 66, Polysulfone, heat-resistant
and self-extinguishing
Soldering terminal: PA 6.6 Ultramide
Actuator housing
Polyamide
Mechanical characteristics
Terminals
Snap-action switching element with tinned soldering terminals at
the sides:
Max. wire diameter 2 wires à 1.2 mm
max. wire cross-section of stranded cable 1x 1 mm²
Snap-action switching element with axial plug-in terminals, which
can also be used as soldering terminals: Plug-in terminal 2.8 x 0.5
mm
Soldering terminal:
Max. wire diameter 2 wires of 1 mm
Max. wire cross-section of stranded cable 2 x 0.75 mm² or 1 x 1.0
mm²
Actuating torque
Measured at the key or lever of the keylock- or selector switch
2.5 Ncm ... 5.5 Ncm, depending on the number of switching
elements
Actuating force
3.5 ... 5.5 N, depending on the number of switching elements
Actuating travel
0
0
Rebound time
5ms
Mechanical lifetime
0
Electrical characteristics
Standards
The devices comply with : EN IEC 61058-1
Rated voltage
250 VAC/DC as per EN IEC 61058-1-15
Contact resistance
New state 50 mΩ as per DIN IEC 60512-2-4
Electrostatic discharge
Keylock switch 15 kV
Rated current
5 A
Conventional free air thermal current I
th
5 A
The maximum current in continuous operation and at ambient
temperature not exceeding the quoted maximum values.
Switch rating
250 VAC, 5 A (cosφ 1)
250 VAC, 3 A (cosφ 0,3)
Switch rating AC (cosφ 0,7)
0
Switch rating DC (inductive) L:R = 30 ms
0
Electric strength
3000 VAC, 50 Hz, 1 min. between all terminals and earth, as per
EN IEC 61058-1-15
Isolation resistance
>7 MΩ between the opend contats at 500 VDC, as per
EN IEC 61058-1-15 (reinforced insulation)
Protection class
II
Environmental conditions
Storage temperature
-40 °C ... +85 °C
Service temperature
-25 °C ... +55 °C
For indicators and illuminated pushbuttons mounted as a block,
make sure the heat can escape freely.
Protection degree
as per EN IEC 60529
front side IP 67
Shock resistance
(semi-sinusoidal)
max. 150 m/s², pulse width 11 ms, 3-axis, as per
EN IEC 60068-2-27
Actuator with snap-action switching element
Illuminated pushbutton: 3 mm
Switch actuator 2 positions:
Momentary action 1 x ca. 42° deflection
momentary action
Maintained action 1 x ca. 90° deflection
maintained action
Switch actuator 3 positions:
Momentary action 2 x ca. 42° deflection
momentary action
Maintained action 2 x ca. 90° deflection
maintained action
Momentary action 2 million Cycles of operation
Maintained action 1 million Cycles of operation
Voltage 125 VAC 250 VAC
Current 3 A 2 A
Voltage 24 VDC 60 VDC 110 VDC 220 VDC
Current 2 A 0.7 A 0.2 A 0.1 A
29
06.2007
14
Technical Data
Vibration resistance
(sinusoidal)
max. 100 m/s² at 10 Hz ... 500 Hz, as per EN IEC 60068-2-6
Climate resistance
Damp heat state as per EN IEC 60068-2-30
Damp heat cyclic as per EN IEC 60068-2-78
Approvals
CE
CB (IEC 61058)
CSA
ENEC (EN 61058)
UL
German Lloyd
RoHS compliant
Switching system
This low level switching element was designed for switching low
powers in electronic circuits. The mechanism assures reliable
switching of loads ranging from a few μA/μV up to 100 mA/42 VAC/
DC.
Single-break momentary contact, as normally open or normally
closed with 4 independent points of contact. 2 momentary contacts
per switching element; combination of normally open and normally
closed is possible.
Special features are the long life, extremely short rebound time and
stable contact resistance.
Material
Material of contact
Gold plated
Switch housing
Polysulfone, heat-resistant and self-extinguishing
Actuator housing
Polyamide
Mechanical characteristics
Terminals
The universal terminals permit these units to be mounted on printed
circuit boards (PCB). These terminals can also be used as
soldering or plug-in terminals.
For these terminals we can also supply a plug-in base which, when
soldered on to the board, enables the switch to be plugged in.
Soldering terminal:
Max. wire diameter 2 wires of 1 mm
Max. wire cross-section of stranded cable 2 x 0.75 mm²
Plug-in terminal: 2.0 x 0.5 mm.
Actuating torque
Measured at the key or lever of the keylock- or selector switch
2.5 Ncm ... 5.5 Ncm, depending on the number of switching
elements
Actuating force
3 ... 4 N, depending on the number of switching elements
Actuating travel
0
Rebound time
typical <100 μs
Mechanical lifetime
Momentary action 5 million cycles of operation
Maintained action 1 million cycles of operation
Electrical characteristics
Contact resistance
New state 50 mΩ as per DIN IEC 60512-2-4
Electrostatic discharge
Keylock switch 15 kV
Switch rating
10 μA, 100 μV to 100 mA at 42 VAC/VDC
Electric strength
3000 VAC, 50 Hz, 1 min. between all terminals and earth, as per
EN IEC 61058-1-15
Protection class
II
Environmental conditions
Storage temperature
-40 °C ... +85 °C
Service temperature
-25 °C ... +55 °C
For indicators and illuminated pushbuttons mounted as a block,
make sure the heat can escape freely.
Protection degree
as per EN IEC 60529
front side IP 67
Shock resistance
(semi-sinusoidal)
max. 150 m/s², pulse width 11 ms, 3-axis, as per
EN IEC 60068-2-27
Buzzer system
System
Piezo disc
Material
Alarm buzzer case
Polyamide
Front cap
Plastic Polyamide
Metal Nickel-plated brass (sea-water proof)
Actuator with low level switching element
Illuminated pushbutton : 3 mm
Switch actuator 2 positions:
Momentary action 1 x ca. 42° deflection
momentary action
Maintained action 1 x ca. 90° deflection
maintained action
Buzzer
30
06.2007
14
Technical Data
Mechanical characteristics
Terminals
Plug-in terminal 2.8 x 0.5 mm
Electrical characteristics
Frequency (tone)
approx. 2.8 kHz continuous tone only
Sound pressure
95 db (A) ±8 dB at a distance of 0.1 m
Operation Voltage/Current
0
Environmental conditions
Storage temperature
-35 °C ... +85 °C
Operating temperature
-25 °C ... +55 °C
Protection degree
as per EN IEC 60529, frontside
IP 40, devices flush mounting
IP 65, devices raised mounting
Approvals
CE
Operation Voltage 24 VDC ±10 %
Operation Current 25 mA
