14 Marking 33 06.2007 All dimensions in mm 0 0 The gap between 2 words results in each case a letter less. 0 Engraving legend plates Dimension Devices mounting style H eight of letters h Number of lines Number of (target…
14
Marking
32
06.2007
0
All dimensions in mm
0
0
The gap between 2 words results in each case a letter less.
All dimensions in mm
0
0
The gap between 2 words results in each case a letter less.
General notes
1. Engraving
In addition to the most commonly used world
languages, in DIN 1451-3 close spacing, other
typefaces are available as Scandinavian,
Slavic, Greek, Russian and Polish.
The lenses are filled with black or white colour.
2. Hot stamping
Standard legends and ISO symbols are hot
stamped. For larger series it is worth
considering markings by means of hot
stamping. We will pleased to advise you.
Engraving marking cap for Indicator round, full face illumination
Height of letters
h
Number of lines Number of (target value) letters per line Line spacing
d
b1 b2 b3
3 3 11 10 9 4.6
4287- 6.6
814- - -
Engraving marking cap for Indicator and illuminated Pushbutton round, front illumination
Height of letters
h
Number of lines Number of (target value) letters per line Line spacing
d
b1 b2 b3
339974.6
4276- 6.6
813- - -
14
Marking
33
06.2007
All dimensions in mm
0
0
The gap between 2 words results in each case a letter less.
0
Engraving legend plates
Dimension Devices mounting style Height of letters
h
Number of lines Number of (target value) letters
per line
30 x 50 round, raised 3 2 12 B1
30 x 50 round, raised 4 1 7 B1
30 x 50 round, raised 8 1 4 B1
35 x 57.5 round, flush 3 2 12 B2
35 x 57.5 round, flush 4 1 7 B2
35 x 57.5 round, flush 8 1 4 B2
Standard texts for marking plates and marking caps for Indicator and Illuminated Pushbuttons
B2B1
50
h
30
57.5
35
Ø25
Ø30.5
14
Marking
34
06.2007
0
Continuation see next page
>
Symbols for marking plates and marking caps for Indicator and Illuminated Pushbuttons
