Chapter 4 Specifications

Maximum rated voltage

between terminals

250 VDC (V ranges) or 30 VDC (mV ranges)

Maximum rated voltage

between terminals and

ground

300 VAC, DC, measurement category II;

anticipated transient overvoltage: 2,500 V

(Between input channels and instrument or between input channels)

Dielectric strength and

insulation resistance

3.0 kVAC for 1 min, 50 MΩ or more at 500 VDC

(Between input channels and instrument or between input channels)

Battery check 3-stage LED display (green, orange, red) (when operating on battery power)

Accuracy is guaranteed even when red indicator is lit.

(green→orange: 6.9 V±0.15 V, orange→red: 6.4 V±0.15 V)

Operating temperature

and humidity

Temperature: 0°C to 40°C (32°F to 104°F)

Humidity: 40% to 80% RH (non-condensing)

Storage temperature and

humidity

Temperature: -20°C to 55°C (-4°F to 131°F)

Humidity: 10% to 80% RH (non-condensing)

Operating environment Indoors, pollution degree 2, up to 2,000 m ASL

Dimensions Approx. 292W × 177H × 182D mm (11.50”W × 6.97”H × 7.17”D)

(excluding protruding parts)

Mass PR8111: Approx. 3.9 kg (137.6 oz) (instrument only)

PR8112: Approx. 4.4 kg (155.2 oz) (instrument only)

Power source Model 9418-15 AC Adapter (12 VDC)

Rated supply voltage: 100 to 240 VAC (with allowance for 10% voltage fluctu-

ations)

Rated supply frequency: 50/60 Hz

Anticipated transient overvoltage: 2,500 V

DC power supply input: 10 to 27 VDC (Input can be provided to the AC adapter

jack via a special-order cable connected.)

Wiring between battery and the instrument must be 3 m or less in length.

Dry-cell batteries: Six LR20 alkaline batteries

(When used with the AC adapter, the adapter takes precedence.)

Max. rated power 4 VA (AC adapter, DC power supply) or 3 VA (dry-cell batteries)

Continuous operating time When using LR20 alkaline batteries (reference values for 23°C)

PR8111: Approx. 50 hours

PR8112: Approx. 25 hours

Test conditions: 60 mm/h chart speed, ±250 mV measurement range, 400

mVp-p 0.01 Hz sine wave input waveform

Applicable standards Safety: EN61010

EMC: EN61326 Class A

EN61000-3-2

EN61000-3-3

Effect of radiated radio-

frequency electromagnet-

ic field

±2% of effective recording with at 10 V/m

Effect of conducted radio-

frequency electromagnetic

field

±2% of effective recording width at 3 V

Chapter 4 Specifications

Accessories

Accessories sold separately

Felt pens PR8111: P-1201A (red)

PR8112: P-1201A (red), P-1202A (green)

Recording paper SE-10Z-2 (fanfold paper) 1

AC adapter 9418-15

Instruction manual 1

Drip-proof vinyl cover 1

Felt pens Red: P-1201A (standard), P-1201B (high-speed), P-1201C (low-speed)

Green: P-1202A (standard), P-1202B (high-speed), P-1202C (low-speed)

Blue: P-1203A (standard), P-1203B (high-speed), P-1203C (low-speed)

Recording paper SE-10Z-2 (fanfold paper), SE-10 (roll paper)
